Industrial gas cylinder LASAL™ 53

gasnitrogenCO2

Overview
LASAL is the Air Liquide brand dedicated to laser applications.

Applications

• Laser cavity gas

Technical specifications (excerpt)
Reference: I6600L50R2A001
Variation name: LASAL 53 Bottle 50L 200 bar
Pressure: 200 bar
Packaging type and size: 50L
Cap: Standard
Capacity: 9.4 m³
Physical state: gaseous
Relative density (gas): Lighter than air
Valve connection: AFNOR C (21.7 x 1.814 SI - right-hand male)
Single molecule: MIX
Components (Vol. % abs): He; CO2 4.5 % ±0.5 %; N2 13.5 % ±1 %
Impurities (see technical datasheet for details): H2O (5 bar) ≤ 5; CnHm ≤ 1
Color: colorless
Odor: odorless

Safety & transport
Hazards: Contains a pressurized gas; may explode if heated. Asphyxiant at high concentration.
Flammability range: non-flammable
Proper shipping name: Compressed gas
UN number: 1956
ADR class: 2
Classification code: 1A

Features / technical specifications

• Reference: I6600L50R2A001
• Variation name: LASAL 53 Bottle 50L 200 bar
• Pressure: 200 bar
• Packaging type and size: 50L
• Capacity: 9.4 m³
• Physical state: gaseous
• Components: He; CO2 4.5 % ±0.5 %; N2 13.5 % ±1 %
• Impurities: H2O (5 bar) ≤ 5; CnHm ≤ 1
• Valve connection: AFNOR C (21.7 x 1.814 SI - right-hand male)
• Color: colorless
• Odor: odorless
• UN number: 1956; ADR class: 2; Classification code: 1A
