Insulated ground clamp MC-281

phase short circuit

Product overview
Earthing and short-circuiting equipment for electric motors rated for 14 kA / 1s. Designed for industrial maintenance and safe earthing during interventions.

Standards
IEC 61230

Applications:

• Earthing and short-circuiting of industrial motors.
• Solution adapted to common issues encountered on industrial engines.
• Ensures safe earthing of installations during maintenance work.
• Easy and safe to handle for technicians.
• Universal compatibility with most installations.
• Allows working on cables with or without lugs.

Features:

• Maximum short-circuit intensity: 14 kA / 1s.
• 1 body made of copper alloy.
• Connection points for cables with lugs: Ø 8 mm to 12 mm.
• Connection points for bare cables: Ø 4 mm to 8 mm.
• Earthing cable: copper, extra-flexible PVC insulation, 50 mm², length 2 m.
• Included earthing clamp: MT-840/1.
• Protection cover included.

Technical table:
Reference: MC-281
Dimensions (mm): 400 x 200
Weight (kg): 1.4

Technical specifications

• Reference: MC-281
• Maximum short-circuit intensity: 14 kA / 1s
• Body material: copper alloy
• Connection points (with lugs): Ø 8 mm to 12 mm
• Connection points (without lugs): Ø 4 mm to 8 mm
• Earthing cable: copper, extra-flexible PVC insulation, 50 mm², length 2 m
• Included earthing clamp: MT-840/1
• Protection cover included
• Dimensions: 400 x 200 mm
• Weight: 1.4 kg
• Standards: IEC 61230
