Indoor air quality monitor PFATH2JS02W AirQ SANI

CO2VOCrelative humidity

Product overview
Integrated system for the sanitization of environments and surfaces through on-board ozone (O3) production, combined with environmental parameters monitoring, local data-logging and publication of dashboards/graphs for rapid assessment of indoor healthiness. Built-in ozone generator capacity: 10,000 mg/h.

Key features

• Ozone generator: 10,000 mg/h
• Sanitization of environments and surfaces via on-board O3 production
• Environmental monitoring with local data-logging and dashboard/graph publication for analysis
• Manual control via front-panel buttons and remote operation via customized web interface accessible from smartphones, tablets and PCs
• Configurable as Master or Slave to create networks of multiple AirQ units
• Wired and wireless connectivity: Ethernet, RS485 serial, Wi‑Fi
• Power supply: 230 Vac ±10% 50 Hz
• White enclosure, dimensions: 350 x 100 x 225 mm
• Optional measured parameters available on request

Measured parameters

• VOC (Volatile Organic Compounds)
• CO2 equivalent (CO2e)
• Temperature (T)
• Relative Humidity (RH)
• Atmospheric Pressure (Pa)
• Optional on request: Ozone (O3)
• Optional on request: Particulate (PM1, PM2.5, PM10)

Connectivity and operation

• Manual control: front-panel buttons
• Remote control: customized web pages (smartphone, tablet, PC)
• Network roles: configurable Master/Slave for multi-unit installations
• Interfaces: Ethernet, RS485 serial, Wi‑Fi

Power and enclosure

• Power supply: 230 Vac ±10% 50 Hz
• Enclosure: white, dimensions 350 x 100 x 225 mm

Documentation
Product data sheet available for download (PDF).

Technical specifications

• Model name: AirQ SANI O3 — PFATH2JS02W
• Ozone generator capacity: 10,000 mg/h
• Control modes: manual (buttons) and remote (web interface)
• Data handling: local data-logging and dashboard/graph publication
• Network topology: Master/Slave configuration supported
• Connectivity: Ethernet, RS485, Wi‑Fi
• Measured parameters: VOC, CO2e, Temperature, RH, Atmospheric Pressure; optional O3 and PM1/PM2.5/PM10
• Power supply: 230 Vac ±10% 50 Hz
• Enclosure colour/size: white, 350 x 100 x 225 mm
