Media separated valve VZDB

diaphragmpneumaticfor control

VZDB is a pneumatic valve and is therefore suitable for environments where electrical signals are to be avoided. • Compact width of 10 mm • Very easy to clean thanks to media separation • High-quality materials, therefore also suitable for aggressive media • For dosing, aspirating and for continuous flow applications • Developed according to ISO 13485 Special characteristics • Very easy to clean thanks to media separation • Low media consumption thanks to small internal volume • High-quality materials, therefore also suitable for aggressive media • High flow rate with small size • High repetition accuracy, switching frequency and precision, therefore also suitable for extremely small volumes and dosing tasks • Extremely flexible in use thanks to 3/2-way and 2/2-way variants Function VZDB is a media separated pneumatic valve. It is used to control gaseous and liquid media in laboratories The valve VZDB is a pilot-actuated pneumatic valve. Normally closed (2/2-way solenoid valve and 3/2-way solenoid valve) and normally open (3/2-way solenoid valve only) variants are available.
