Corded electric screwdriver eTensil E8C AP series

pistolwith shut-off clutchbrushless

PISTOL GRIP ELECTRIC SCREWDRIVER WITH MECHANICAL CLUTCH AND AUTOMATIC SHUT-OFF
Forward pistol-grip brushless electric screwdriver with mechanical clutch and automatic shut-off, designed and manufactured by Fiam in Italy.

Overview
Brushless electric screwdriver engineered for industrial assembly lines. Compact, energy-efficient and reliable, the tool is suited to Industry 4.0 environments and can be integrated into smart production systems across multiple sectors.

Tightening control and user interface
Equipped with a mechanical clutch torque control system that cuts power when the preset torque is reached. The system ensures high repeatability and very low Mean Shift even with variable joint elasticity, maintaining consistent values over millions of cycles. The reversible button supports multifunction programming and the tool features 6 LED indicators for tightening feedback.

Ergonomics and grip
Forward pistol-grip designed for right- and left-handed operators and adapted for smaller hands. Ideal for vertical fastening points. The handle has an ergonomic, non-slip molded sheath to improve grip, handling, thermal insulation and operator comfort.

Tool functionality with TPU-1 and TPU-2 power units

• LOW-HIGH idle speed: LOW ≈ 80% of max speed indicated in the technical table
• Front illumination LED: on/off
• UNTIGHTENING INHIBITION
• SOFT START: from rest to rated speed in 1.5 s
• PRE-AUTO UNTIGHTENING: 4 turns (useful when previously tightened parts must be loosened before torque setting)
• POST-AUTO UNTIGHTENING: 4 turns (useful when tightening to set torque then loosening for subsequent assembly)

Tool functionality with TPU-M1 monitoring unit

• 8 programs to control the tightening process
• 1 programmable sequence up to 8 steps
• Retention: programmable waiting interval between programs
• Manage tightening of critical joints
• Idle speed range: adjustable within the indicated range
• Front LED: adjustable intensity
• Untightening: enable/disable, settable speed
• Soft start: adjustable acceleration time
• Pre-auto untightening: set angle and pause before tightening
• Post-auto untightening: set angle and pause before left rotation after tightening
• Stop-by-time tightening: tighten by depth/time without defining torque
• Industry 4.0: interconnectable with factory management systems

Features

• Connecting cable supplied
• Quick-change chuck
• ESD certified
• "Smart Pro" multifunction programming
• Extended warranty: 2 years or 1,000,000 cycles

Industrial sectors
General industry; Household appliance; Motor vehicle industry and components; Electronics; Aerospace; Doors and windows frames

Technical specifications

• Models: 8 type with feeding from the bottom, 8 type with feeding from the top, 8 type with up grip and feeding from the top
• Tightening torque range (Lb): 2.6 ÷ 39.8
• Tightening torque range (Nm): 0.3 ÷ 4.5
• Free speed range (rpm): 170 - 2000
• Accessory drive: FEMALE HEXAGONAL DRIVE 1/4"
• Cable length (m): 3
• Dimensions (mm): L 251 x H 177 x Ø 44
• Feed unit to use: TPU-1 / TPU-2
• Grip: Pistol with top feeding
• Monitoring unit to use: TPU-M1
• Operating voltage (Vdc): 32
• Reversibility: Reversible
• Starting system: Push button
• Supply voltage (Vac): 100 - 240
• Tightening technologies: Mechanical clutch with automatic shut-off
• Weight (Lb): 1.87
• Weight (Kg): 0.85
