Spring locating pin CP721 series

tapped shankretractable

Description
These through-style locator pins are part of the Flex clamping locator system. They are designed to be mounted on fixture bases and plates for accurate locating and positioning and provide reliable re-positioning with 0.01 mm repeatability. Suitable for both vertical and horizontal applications. The through-style pins engage corresponding receiver bushings by screwing down a single clamping screw through the pin and bushing; this action retracts the spring-loaded receiver bushing and allows the fixture plate to contact the base plate. Manufactured from nitrocarburized treated 4140 alloy steel for improved wear resistance.

Part options (table)
Part Number | Thread - Depth | D (mm) | D1 (mm) | D2 (mm) | H (mm) | H1 (mm) | Use Receiver Bushing
CP721-12025 | M10x1.50 - Depth 3.5 | 15 | 12 | 8.5 | 10 | 4.5 | CP726-12025
CP721-15032 | M12x1.75 - Depth 4.5 | 20 | 15 | 10.2 | 15 | 7.5 | CP726-15032
CP721-20045 | M16x2.00 - Depth 5.5 | 30 | 20 | 14 | 20 | 10 | CP726-20045

Accessories

• CP726 receivers — use with Flex CP721 locators
• CP726-P protective covers — use with CP726 Flex receivers

Media

• Product video available
• Specifications PDF available

Technical specifications

• Model: CP721 (through-style locator pin)
• Material: nitrocarburized treated 4140 alloy steel
• Repeatability: 0.01 mm
• Applications: suitable for both vertical and horizontal fixture locating
• Operation: through-style pins engage corresponding bushings by screwing down a single clamping screw through the pin and bushing, retracting the spring-loaded receiver bushing to allow fixture plate contact with base plate
• Compatible receiver bushings: CP726 series (examples: CP726-12025, CP726-15032, CP726-20045)
• Available variants / dimensions:

  • CP721-12025 — Thread: M10x1.50 (Depth 3.5); D=15 mm; D1=12 mm; D2=8.5 mm; H=10 mm; H1=4.5 mm
  • CP721-15032 — Thread: M12x1.75 (Depth 4.5); D=20 mm; D1=15 mm; D2=10.2 mm; H=15 mm; H1=7.5 mm
  • CP721-20045 — Thread: M16x2.00 (Depth 5.5); D=30 mm; D1=20 mm; D2=14 mm; H=20 mm; H1=10 mm
