Panel-mount indicator D090

processtemperaturecurrent loop

The D090-A-PL is an economical, DIN panel mount, loop powered multi-purpose indicator with large 26mm (1”) high digits which displays the actual process value, range and loop current. The measuring unit to be displayed is simply selected through an alfa-numerical configuration menu. No adhesive labels have to be put on the outside of the enclosure: a weather proof and user friendly solution! The configuration of Span, offset and number of decimals is done through software functions, without any sensitive dip-switches or trimmers. It accepts a wide range of process instruments, including flow (linear or square root), level, pressure and temperature transmitters. All these process parameters can be displayed in their own engineering units. Advantages - Unique, robust IP66, IP67 (NEMA Type4X) panel mount front enclosure made of die cast aluminum, allowing even big jets of water and total immersion. - Familiar easy operation with the Fluidwell "Know one, know them all" configuration structure, saving time, cost and aggravation. Features - Very large 26mm (1") digits. - Displays the actual value, measuring unit and loop current. - Selectable on-screen time units for flow rate: /sec, /min, /hour, /day or no unit. - Piegraph indication: ten segments. - Auto backup of all settings. - Ambient temperature: -40°C to +80°C (-40°F to 176°F). - Easy configuration with clear alphanumerical display. - Aluminum DIN front panel of 144 x 72mm (5.67” x 2.83”) according DIN 43700 / IEC 61554. - Various accessories are available for this product.
