Simple cuve adsorber GFC2

activated carbondouble-cuve

Short description
GeoFilter GFC2 is an activated carbon filter unit designed to remove odours, gases, aerosols and volatile organic compounds (VOCs) from industrial return, intake or recirculated air. It uses refillable activated carbon cartridges with low pressure drop to provide reliable air purification for indoor or outdoor installation (outdoor under protective cover).

What do you get?

• Effective removal of odours, gases, aerosols and VOCs.
• Refillable galvanized steel cartridges containing approx. 23 kg activated carbon each.
• Minimal pressure drop and stable airflow for energy-efficient operation.
• Galvanised steel housing suitable for industrial environments.
• Available in single-stage and dual-stage configurations.
• Quick and easy servicing without special tools.
• Suitable for return air, intake air and recirculated air streams.

Product information
The GeoFilter GFC2 housing is manufactured from galvanised steel for mechanical strength and corrosion resistance. Filtration is performed by refillable activated carbon cartridges; the carbon type can be selected to match the application for optimal removal of specific gases and odours. Single-stage units treat air in one pass; dual-stage units provide two sequential filtration stages to increase contact time and improve removal efficiency for demanding applications.

Additional features

• Designed for long-term, reliable operation with low maintenance requirements.
• Serviceable cartridges: spent carbon can be removed and replaced without special tools.
• Low pressure drop to reduce energy consumption.
• Compatible with return, intake and recirculated air systems.

Technical data

• Material: Galvanised steel
• Installation: Indoor / Outdoor (under protective cover)
• Max. air volume: 300-400 m³/h
• Stage: single-stage / dual-stage
• Weight on coal (per variant): 138 kg; 207 kg; 275 kg; 275 kg; 414 kg; 552 kg
• Connections: Inlet ø450 mm, Outlet ø450 mm
• Dimensions (L x W x H) (variants): 2,055 x 850 x 1,660 mm; 2,055 x 1,210 x 1,660 mm; 2,055 x 1,660 x 1,660 mm; 4,110 x 850 x 1,660 mm; 4,110 x 1,210 x 1,660 mm; 4,110 x 1,660 x 1,660 mm
• Overall weight (per variant): 768 kg; 757 kg; 925 kg; 1,155 kg; 1,390 kg; 1,630 kg

Characteristics / technical specifications

• Brand: Geovent
• Model: GFC2
• Housing material: Galvanised steel
• Installation: Indoor or outdoor (under protective cover)
• Filtration media: Refillable activated carbon cartridges (approx. 23 kg carbon per cartridge)
• Configurations: Single-stage and dual-stage options
• Max. air volume: 300-400 m³/h
• Connections: Inlet ø450 mm, Outlet ø450 mm
• Dimensions (L x W x H) (available variants): 2,055 x 850 x 1,660 mm; 2,055 x 1,210 x 1,660 mm; 2,055 x 1,660 x 1,660 mm; 4,110 x 850 x 1,660 mm; 4,110 x 1,210 x 1,660 mm; 4,110 x 1,660 x 1,660 mm
• Weight on coal (variant-dependent): 138 kg; 207 kg; 275 kg; 275 kg; 414 kg; 552 kg
• Overall weight (variant-dependent): 768 kg; 757 kg; 925 kg; 1,155 kg; 1,390 kg; 1,630 kg
• Maintenance: Quick servicing without special tools; cartridges are refillable and replaceable
• Applications: Return air, intake air, recirculated air; industrial air purification for odours, gases, aerosols and VOCs
