Automatic pipe threading machine IMC series

Product description
Portable IMC series pipe threading machines provide on-site pipe threading and preparation for mechanical and plumbing installations. Built for field use, the units accept a range of pipe sizes and standard threading dies for BSP, NPT or BSPT threads. The machines are designed for straightforward maintenance and sustained operation with regular servicing.

Customization
Industrial Machinery Corporation offers the IMC series in multiple configurations. Customization options include model/size range, die‑head combinations, included threading dies, motor specification and overall weight to match workshop or site requirements. Configurable elements help select the optimal unit for production or on-site threading tasks.

Considerations
When selecting a portable pipe threader, consider: material and coating for abrasion and water resistance, supplied die‑head sizes, compatibility with required thread standards (BSP, NPT, BSPT), motor power and RPM, and machine weight for transport and handling. These criteria determine durability and suitability for specific applications.

Available Options

• Thread Type
  • BSP
  • NPT
  • BSPT
  • Others
  • Don't Know Exactly
• Purchase (lead time)
  • Immediately
  • Within a week
  • Within 15 days
  • Within a month
  • Others
  • Don't Know Exactly

Specifications

• Model: IMC-1/2" to 2" — Sizes: 1/2" to 2" — Specification: 230V/50 Hz, 750W, 27RPM — Threading die‑head included: 1/2" - 2" — Threading dies included: 1/2" - 3/4" & 1" - 2" (BSPT or NPT) — Weight: 81 Kgs.
• Model: IMC-1/2" to 3" — Sizes: 1/2" to 3" — Specification: 230V/50 Hz, 750W, 26/11RPM — Threading die‑head included: 1/2" - 2" & 2.1/2" - 3" — Threading dies included: 1/2" - 3/4", 1" - 2" & 2.1/2" - 3" (BSPT or NPT) — Weight: 135 Kgs.
• Model: IMC-1/2" to 4" — Sizes: 1/2" to 4" — Specification: 230V/50 Hz, 750W, 26/10RPM — Threading die‑head included: 1/2" - 2" & 2.1/2" - 4" — Threading dies included: 1/2" - 3/4", 1" - 2" & 2.1/2" - 4" (BSPT or NPT) — Weight: 150 Kgs.
• Model: IMC-2.1/2" to 6" — Sizes: 2.1/2" to 6" — Specification: 230V/50 Hz, 750W, 26/10RPM — Threading die‑head included: 2.1/2" - 4" & 5" - 6" — Threading dies included: 2.1/2" - 4" & 5" - 6" (BSPT or NPT) — Weight: 215 Kgs.
