Brinell hardness tester HBM-3000Dbenchtopfor steelfor large components
Add to favorites
Compare this product
Characteristics
- Type
- Brinell
- Mounting
- benchtop
- Product applications
- for steel, for large components, metal, for hard plastics, for aluminum, for production, for cast parts, for thin workpieces, for metallographic samples, for industrial applications, for metal sheets, for laboratories, for quality control, industrial, for stainless steel, for laboratory applications, for measurement instruments, for soft materials, for pipes
- Other characteristics
- digital display, automatic, motorized, micro, mechanical, with printer, cost-effective, with data logger, with image analysis
- Load
750 kgf, 1,000 kgf, 3,000 kgf
Description
Brief introduction:
This machine adopts automatic closed-loop control force sensor system.
Overload automatic protection and electronic control.It is solid in construction and good rigidity, precise, reliable, durable, high test efficiency. Test process automation control, no human operation error. Large LCD screen, the menu smart tips, easy to operate; The high precision reading microscope measurement system.
Application and scope:
Determination of ferrous metal, nonferrous metal and brinell hardness of the bearing alloy material.Wide scope of application, especially for precision measurement of parallel plane.
Technical specifications:
Test range：４-450HBS, ４-650HBW
Test force： （750、1000、3000kgf）
Max height of test piece: 1200mm（customized）
Worktable width：750mm（customized）
Power supply:220V/50HZ
Dimensions：1200mm x 1150mm x 1800mm（customized）
Weight：about 1500KG
Standard accessories:
Large flat anvil:1pc
Little flat anvil:1pc
V style flat anvil:1pc
Tungsten carbide ball penetrator: Φ2.5,Φ5,Φ10,1pc.each;
Brinell standardized block:2pces;
20X readout microscope:1 pc.
