Nodular cast iron construction
Long cooling length displacing seal away from the pumped liquid
Back vanes and labyrinth prevent solids from reaching bearing and seals
Product lubricated slide bearing
Standard mechanical seal
CombiTherm ensures uniform process temperatures while keeping damaging heat away from seal faces and bearings. CombiTherm is designed to require no external cooling when working within the given parameters. The throttle bush, journal bearing and seal placement reduce circulation and temperature along the pump length. This greatly reduces the temperature at the seal face and bearings.
Suitable for
Thermal oil heat transfer: OEM systems, maintaining temperature in jacketed equipment
Marine and Floating Production Systems: Fuel tank heaters and fuel preheating, cargo and product heating, steam generation
Food: Ovens, fish frying, distillation of fatty acids and glycerine, fat softening, potato chips, milk powder plants
Bitumen: Asphalt production, roads and roofing
Rubber and plastics: Injection molding, PVC tape, manmade fibers
Chemical: Agitators, reactors, drying plants, polymerisation, plastics
Paper and wood: Calender rolls, cardboard, washing machines, driers, floor board and wood panel
High temperature hot water circulation: Hospitals, heating systems
