Truck-mounted telescopic boom lift Xtenso 4®

hydraulicgasworkshop

Overview
The Xtenso 4 access platform mounted on a 16T truck reaches a working height of 21 m and a lateral outreach of 16.40 m. It is designed for infrastructure professionals who need to lift tools and materials to high work zones, offering a constant capacity of up to 265 kg including during use of the telescopic function of the articulated jib. The vehicle-mounted platform is equipped with a large workshop area for storing tools and materials, which can be fitted with tailored racking and shelving.

Key figures

• Working height: 21.00 m (68'90")
• Working outreach: 16.40 m (53'10")
• Boom rotation: 420°
• Maximum working load: 265 kg
• Maximum platform height: 19 m (62'40")
• Outriggers: H-Shaped outriggers
• Basket size: 89 x 115 x 156 cm
• Chassis weight: + 3.5T
• Arm: Telescopic
• Engine: Gas
• IPAF category: 1b
• Lifting mechanism: Hydraulic
• Maximum permissible wind speed for use: 45 km/h
• Maximum slope: 15%
• Maximum tilt: 5%

Standard Features

• Engine start and stop from basket
• Stabilization with independent controls in the basket and from the ground
• Independent emergency manual pump
• Proportional controls on all movements
• Secure access to the working platform
• Hoses and cables are inside the boom structure for maximum protection
• Automatic centering of the platform and the turret
• Lifting arm consisting of a double telescope and a telescopic jib with 180° orientation
• Telescopic jib for an overhang of more than 5.10 m allowing 360° access to the ground
• Hydraulic rotation of the basket in all positions

Examples of vehicles

• Renault D16
• Volvo FL42
• MAN TGM
• Iveco Eurocargo
• Mercedes Atego/Arocs

Description
The Xtenso 4 range of truck-mounted platforms features articulated telescopic jibs capable of overcoming obstacles such as tree branches, roofs, balconies and electric cables, enabling operators to get as close as possible to the work zone. The workshop version includes a large workshop space integrated into the vehicle for onsite storage and organization of tools and materials.

Technical specifications

• Max. working height: 21 m (68'11")
• Max. working outreach: 16.40 m (53'10")
• Boom rotation: 420°
• Max. working load: 265 kg
• Max. platform height: 19 m (62'40")
• Outriggers: H-Shaped outriggers
• Basket size: 89 x 115 x 156 cm
• Chassis weight: + 3.5T
• Arm: Telescopic
• Engine: Gas
• IPAF category: 1b
• Lifting mechanism: Hydraulic
• Max. permissible wind speed for use: 45 km/h
• Max. slope: 15%
• Max. tilt: 5%
