Synchronous torque motor CWFL05215-04030NW48-S000

brushless3-phase48 V

Overview
The CWFL05215-04030NW48-S000 is a φ52 mm frameless torque motor kit with a 15 mm stator stack, delivering 0.40 N·m rated torque and 1.20 N·m peak torque at 3000 RPM on 48 VDC. The 16-pole 3-phase PMSM topology provides exceptionally smooth low-speed torque, suitable for precision rotary tables, medical imaging gantries, and semiconductor wafer handling.

KEY HIGHLIGHTS

• φ52 mm stator OD with a slim 15.4 mm stack for axially constrained designs
• 0.40 N·m rated / 1.20 N·m peak torque at 3000 RPM on 48 VDC
• 16-pole 3-phase permanent magnet synchronous motor (PMSM) for ultra-smooth low-speed operation
• Class F insulation (155 °C); optional Hall and temperature sensors
• Customizable stator stack length, bore ID and winding; no MOQ for custom variants

Product Datasheet
Product datasheet available: CWFL05215-04030NW48-S000

Electrical Specifications (48 VDC)
Model: CWFL05215-04030NW48-S000
Rated Voltage: 48 VDC
Rated Current: 3.8 A
Peak Current (instantaneous): 11.4 A
Rated Output Power: 126 W
Rated Speed: 3000 RPM
Rated Torque: 0.40 N·m
Peak Torque (instantaneous): 1.20 N·m
Back-EMF Constant (Ke): 7.3 Vrms/krpm
Torque Constant (Kt): 0.1050 N·m/A
Rotor Inertia: 7.22 × 10⁻⁶ kg·m²
Poles: 16
Insulation Class: F (155 °C)
Weight: 0.21 kg
Operating Environment: −20 °C to +40 °C; Humidity ≤ 90% RH

Dimensional Parameters
Ls (Stator stack length): 15.4 mm
Lr (Rotor length): 18.4 mm
ØD (Stator OD): 52 mm
Ød (Bore ID, H7): 16.8 mm
ØA min: 31.2 mm
ØB max: 49 mm
ØC max (both ends): 51 mm
E max: 5.1 mm
F max: 9.1 mm

Wiring & Sensor Options
Power leads: 3 wires (U/V/W), L = 200 mm, TEFLON insulation; U — Red, V — White, W — Black
Hall sensor (optional): 5 wires — Vcc, GND, HA (Green), HB (Blue), HC (White), L = 200 mm, TEFLON
Temperature sensor (optional): 2 wires — + (Orange), − (Yellow), L = 200 mm, TEFLON
Bearing: Not included — host structure must provide bearing

Available Voltage Configurations
12 VDC — winding parameters: not specified for this listing
24 VDC — winding parameters: not specified for this listing
48 VDC — CWFL05215-04030NW48-S000: 3.8 A rated, 11.4 A peak, Ke = 7.3 Vrms/krpm, Kt = 0.1050 N·m/A
Custom — stack thickness, bore ID, winding and sensor type configurable (parameters not specified in this listing)

Mechanical & Performance Drawings
Dimensional drawing and torque–speed characteristic images are provided with the product listing (illustrative only; see datasheet for detailed dimensions and curves).

Technical specifications

• Model: CWFL05215-04030NW48-S000
• Stator OD: φ52 mm
• Stator stack length (Ls): 15.4 mm
• Rotor length (Lr): 18.4 mm
• Rated Voltage: 48 VDC
• Rated Current: 3.8 A
• Peak Current: 11.4 A
• Rated Torque: 0.40 N·m
• Peak Torque: 1.20 N·m
• Rated Speed: 3000 RPM
• Rated Power: 126 W
• Back-EMF Constant (Ke): 7.3 Vrms/krpm
• Torque Constant (Kt): 0.1050 N·m/A
• Rotor Inertia: 7.22 × 10⁻⁶ kg·m²
• Poles: 16
• Insulation Class: F (155 °C)
• Weight: 0.21 kg
• Bore ID (Ød, H7): 16.8 mm
• ØA min: 31.2 mm; ØB max: 49 mm; ØC max (both ends): 51 mm; E max: 5.1 mm; F max: 9.1 mm
• Power leads: 3-wire TEFLON, 200 mm (U red, V white, W black)
• Optional sensors: Hall sensor (5-wire), temperature sensor (2-wire)
• Bearing: not included (host provides bearing)
