Brushless torque motor CWFL08834-26030NW48-S000

synchronous3-phase48 V

Product Overview
The CWFL08834-26030NW48-S000 is a φ88 mm B-series frameless torque motor kit delivering 2.60 N·m rated torque and 7.80 N·m peak torque at 3000 RPM on 48 VDC. The 10-pole 3-phase PMSM design provides high torque output for direct-drive applications such as industrial robot base joints, heavy-duty rotary tables, and large-format gimbal systems.

Key Highlights

• φ88 mm stator OD, 34 mm stack (B-series) for high torque output
• 2.60 N·m rated / 7.80 N·m peak torque at 3000 RPM on 48 VDC
• 10-pole 3-phase PMSM with sinusoidal back-EMF for smooth FOC control
• Class F insulation (155 °C); optional Hall sensor + temperature sensor
• Custom stator stack, bore ID, and winding — no minimum order

Product Datasheet
Product datasheet reference: CWFL08834-26030NW48-S000

Electrical Specifications (48 VDC)
Model: CWFL08834-26030NW48-S000
Rated Voltage: 48 VDC
Rated Current: 24.4 A
Peak Current (Instantaneous): 73.3 A
Rated Output Power: 817 W
Rated Speed: 3000 RPM
Rated Torque: 2.60 N·m
Peak Torque (Instantaneous): 7.80 N·m
Back-EMF Constant (Ke): 7.4 Vrms/krpm
Torque Constant (Kt): 0.1064 N·m/A
Rotor Inertia: 9.20 × 10⁻⁵ kg·m²
Poles: 10
Insulation Class: F (155 °C)
Weight: 1.2 kg
Operating Environment: −20 °C to +40 °C; Humidity ≤ 90% RH

Dimensional Parameters
Ls (Stator Stack Length): 34.3 mm
Lr (Rotor Length): 37.3 mm
ØD (Stator OD): 88 mm
Ød (Bore ID, H7): 33 mm
ØA min: 50.2 mm
ØB max: 82.1 mm
ØC max (both ends): 86 mm
E max: 7.3 mm
F max: 11.3 mm

Wiring & Sensor Options
Power Leads: 3 wires (U/V/W), L = 200 mm, TEFLON insulation; U — Red, V — White, W — Black
Hall Sensor (optional): 5 wires: Vcc, GND, HA (Green), HB (Blue), HC (White) — L = 200 mm, TEFLON
Temperature Sensor (optional): 2 wires: + (Orange), − (Yellow) — L = 200 mm, TEFLON
Bearing: Not included — host structure provides bearing

Available Voltage Configurations
36 VDC: configuration listed for series (detailed winding parameters not specified on page)
48 VDC: CWFL08834-26030NW48-S000 — 24.4 A rated, 73.3 A peak, Ke = 7.4 Vrms/krpm, Kt = 0.1064 N·m/A
60 VDC: configuration listed for series (detailed winding parameters not specified on page)
Custom: stack thickness, bore ID, winding, sensor type — configurable options available

Illustrations
Dimensional drawing and torque-speed characteristic images are provided on the product page (visual references: dimensional drawing and torque-speed characteristic charts).

Technical specifications

• Model: CWFL08834-26030NW48-S000
• Stator OD: 88 mm
• Stator stack length (Ls): 34.3 mm
• Rated Voltage: 48 VDC
• Rated Current: 24.4 A
• Peak Current: 73.3 A
• Rated Torque: 2.60 N·m
• Peak Torque: 7.80 N·m
• Rated Speed: 3000 RPM
• Rated Output Power: 817 W
• Poles: 10 (10-pole 3-phase PMSM)
• Back-EMF (Ke): 7.4 Vrms/krpm
• Torque Constant (Kt): 0.1064 N·m/A
• Rotor Inertia: 9.20 × 10⁻⁵ kg·m²
• Insulation Class: F (155 °C)
• Weight: 1.2 kg
• Operating Environment: −20 °C to +40 °C; Humidity ≤ 90% RH
• Power leads length: 200 mm, TEFLON insulated
• Optional sensors: Hall (5-wire) and temperature (2-wire)
