Synchronous torque motor CWFL06013-04530NW48-S000

three-phase48 Vpermanent magnet

Overview The CWFL06013-04530NW48-S000 is a φ60 mm A-series frameless torque motor kit featuring a 13.3 mm slim stator stack and a 30 mm bore (H7) that permits shaft or cable pass-through without increasing outer envelope. This 16-pole, 3-phase PMSM delivers 0.45 N·m rated and 1.35 N·m peak torque at 3000 RPM on 48 VDC with very smooth low-speed ripple, ideal for compact rotary axes such as medical imaging gantries, semiconductor wafer handlers, and hollow-shaft rotary stages.

Key Highlights

• φ60 mm stator OD with 13 mm slim stack (A-series) for axially constrained designs
• 0.45 N·m rated / 1.35 N·m peak torque at 3000 RPM (48 VDC)
• 16-pole, 3-phase PMSM for ultra-smooth low-speed operation
• Insulation Class F (155 °C); optional Hall and temperature sensors
• Customizable stator stack, bore ID and winding; no MOQ for customizations

Quick Specs Rated Voltage: 48 VDC
Rated Torque: 0.45 N·m
Peak Torque: 1.35 N·m
Rated Speed: 3000 RPM
Rated Power: 141 W
Stator OD: φ60 mm

Electrical Specifications (48 VDC) Model: CWFL06013-04530NW48-S000
Rated Voltage: 48 VDC
Rated Current: 4.3 A
Peak Current (instantaneous): 12.9 A
Rated Output Power: 141 W
Rated Speed: 3000 RPM
Rated Torque: 0.45 N·m
Peak Torque (instantaneous): 1.35 N·m
Back-EMF Constant (Ke): 7.3 Vrms/krpm
Torque Constant (Kt): 0.1050 N·m/A
Rotor Inertia: 1.60 × 10^-5 kg·m²
Poles: 16
Insulation Class: F (155 °C)
Weight: 0.22 kg
Operating Environment: −20 °C to +40 °C; Humidity ≤ 90% RH

Dimensional Parameters Ls (Stator stack length): 13.3 mm
Lr (Rotor length): 16.3 mm
ØD (Stator OD): 60 mm
Ød (Bore ID, H7): 30 mm
ØA min: 41.4 mm
ØB max: 57 mm
ØC max (both ends): 59 mm
E max: 5.3 mm
F max: 9.3 mm

Wiring & Sensor Options Power leads: 3 wires (U/V/W), L = 200 mm, TEFLON insulation; U — Red, V — White, W — Black
Hall sensor (optional): 5 wires — Vcc, GND, HA (Green), HB (Blue), HC (White) — L = 200 mm, TEFLON
Temperature sensor (optional): 2 wires — + (Orange), − (Yellow) — L = 200 mm, TEFLON
Bearing: Not included — host structure provides bearing

Available Voltage Configurations 12 VDC — variant CWFL06013-04530NW12-S000 (winding parameters vary)
24 VDC — variant CWFL06013-04530NW24-S000 (winding parameters vary)
48 VDC — CWFL06013-04530NW48-S000: 4.3 A rated, 12.9 A peak, Ke = 7.3 Vrms/krpm, Kt = 0.1050 N·m/A
Custom — stack thickness, bore ID, winding and sensor options available (parameters vary)

Drawings & Charts Dimensional drawing and torque-speed characteristic charts are available in the product images and technical datasheet.

Technical Specifications

• Series: CWFL φ60mm-A
• Model (SKU): CWFL06013-04530NW48-S000
• Rated Voltage: 48 VDC
• Rated Torque: 0.45 N·m
• Peak Torque: 1.35 N·m
• Rated Speed: 3000 RPM
• Rated Power: 141 W
• Stator OD: φ60 mm
• Bore ID (H7): 30 mm
• Stator stack length (Ls): 13.3 mm
• Rotor length (Lr): 16.3 mm
• Poles: 16
• Torque constant (Kt): 0.1050 N·m/A
• Back-EMF constant (Ke): 7.3 Vrms/krpm
• Rated current: 4.3 A; Peak current: 12.9 A
• Rotor inertia: 1.60 × 10^-5 kg·m²
• Insulation class: F (155 °C)
• Weight: 0.22 kg
• Operating environment: −20 °C to +40 °C; Humidity ≤ 90% RH
• Power lead construction: TEFLON insulated, 200 mm length
• Optional sensors: Hall (5-wire) and temperature sensor (2-wire)
• Bearing: not included (host-provided)
