Brushless torque motor CWFL07633-18030NW48-S000

synchronousthree-phase36 V

Product overview
The CWFL07633-18030NW48-S000 is a φ76 mm B-series frameless torque motor kit offering 1.80 N·m rated torque and 5.40 N·m peak torque at 3000 RPM on 48 VDC. This 10-pole, 3-phase PMSM with sinusoidal back-EMF is optimised for direct-drive applications such as industrial robot joints, rotary tables and large gimbals.

KEY HIGHLIGHTS

• φ76 mm stator OD, 33 mm stack (B-series) for high torque density
• Rated torque 1.80 N·m / Peak torque 5.40 N·m at 3000 RPM (48 VDC)
• 10-pole 3-phase PMSM with sinusoidal back-EMF — smooth FOC control
• Class F insulation (155 °C); optional Hall and temperature sensors
• Customisable stator stack, bore ID and winding; no MOQ for standard options

Electrical specifications (48 VDC)
Model — CWFL07633-18030NW48-S000
Rated voltage — 48 VDC
Rated current — 16.9 A
Peak current (instantaneous) — 50.7 A
Rated output power — 565 W
Rated speed — 3000 RPM
Rated torque — 1.80 N·m
Peak torque (instantaneous) — 5.40 N·m
Back-EMF constant (Ke) — 7.4 Vrms/krpm
Torque constant (Kt) — 0.1064 N·m/A
Rotor inertia — 6.26 × 10⁻⁵ kg·m²
Poles — 10
Insulation class — F (155 °C)
Weight — 0.88 kg
Operating environment — −20 °C to +40 °C; humidity ≤ 90% RH

Dimensional parameters
Ls (stator stack length) — 32.9 mm
Lr (rotor length) — 35.9 mm
ØD (stator OD) — 76 mm
Ød (bore ID, H7) — 28 mm
ØA min — 45.2 mm
ØB max — 70.5 mm
ØC max (both ends) — 74 mm
E max — 6.5 mm
F max — 10.5 mm

Wiring & sensor options
Power leads — 3 wires (U/V/W), L = 200 mm, TEFLON insulation; U — Red, V — White, W — Black
Hall sensor (optional) — 5 wires: Vcc, GND, HA (Green), HB (Blue), HC (White) — L = 200 mm, TEFLON
Temperature sensor (optional) — 2 wires: + (Orange), − (Yellow) — L = 200 mm, TEFLON
Bearing — not included; host structure provides bearing

Available voltage configurations
36 VDC — winding parameters not specified on this page
48 VDC — CWFL07633-18030NW48-S000: 16.9 A rated, 50.7 A peak, Ke = 7.4 Vrms/krpm, Kt = 0.1064 N·m/A
60 VDC — winding parameters not specified on this page
Custom — stack thickness, bore ID, winding and sensor type configurable (parameters vary)

Product datasheet
Datasheet identifier — CWFL07633-18030NW48-S000

Technical specifications

• Series — CWFL φ76 mm-B (long stack)
• Rated voltage — 48 VDC (other windings available)
• Rated torque — 1.80 N·m
• Peak torque — 5.40 N·m
• Rated speed — 3000 RPM
• Rated output power — 565 W
• Poles — 10 (10-pole 3-phase PMSM)
• Back-EMF (Ke) — 7.4 Vrms/krpm
• Torque constant (Kt) — 0.1064 N·m/A
• Rated current — 16.9 A; Peak current — 50.7 A
• Rotor inertia — 6.26 × 10⁻⁵ kg·m²
• Stator OD — 76 mm; Bore ID H7 — 28 mm
• Insulation class — F (155 °C)
• Weight — 0.88 kg
• Operating temperature — −20 °C to +40 °C; humidity ≤ 90% RH
• Optional sensors — Hall sensor (5-wire), temperature sensor (2-wire)
