Electric stacker truck CDD15R-EN
walk-behind24 Vfor materials handling

Electric stacker truck - CDD15R-EN - NINGBO RUYI JOINT STOCK CO., LTD - walk-behind / 24 V / for materials handling
Electric stacker truck - CDD15R-EN - NINGBO RUYI JOINT STOCK CO., LTD - walk-behind / 24 V / for materials handling
Electric stacker truck - CDD15R-EN - NINGBO RUYI JOINT STOCK CO., LTD - walk-behind / 24 V / for materials handling - image - 2
Electric stacker truck - CDD15R-EN - NINGBO RUYI JOINT STOCK CO., LTD - walk-behind / 24 V / for materials handling - image - 3
Electric stacker truck - CDD15R-EN - NINGBO RUYI JOINT STOCK CO., LTD - walk-behind / 24 V / for materials handling - image - 4
Add to favorites
Compare this product
Go to the NINGBO RUYI JOINT STOCK CO., LTD website for more information

Characteristics

Energy
electric
Operator
walk-behind
Voltage
24 V
Applications
for materials handling, for warehouse, for lifting
Other characteristics
compact
Carrying capacity

Min.: 0 kg
(0 lb)

Max.: 1,500 kg
(3,306.9 lb)

Lifting height

Min.: 1,600 mm
(62.99 in)

Max.: 3,500 mm
(137.8 in)

Height of mast when lowered

Min.: 2,090 mm
(82.3 in)

Max.: 2,340 mm
(92.1 in)

Height of mast when raised

Min.: 2,090 mm
(82.28 in)

Max.: 4,060 mm
(159.84 in)

Overall width

Min.: 600 mm
(23.6 in)

Max.: 600 mm
(23.6 in)

Overall length

Min.: 1,720 mm
(67.7 in)

Max.: 1,800 mm
(70.9 in)

Fork width

Min.: 300 mm
(11.8 in)

Max.: 695 mm
(27.4 in)

Fork length

Min.: 1,070 mm
(42.13 in)

Max.: 1,150 mm
(45.28 in)

Fork thickness

Min.: 90 mm
(3.54 in)

Max.: 90 mm
(3.54 in)

Turning circle radius

Min.: 1,365 mm
(53.7 in)

Max.: 1,365 mm
(53.7 in)

Battery capacity

Min.: 105 Ah

Max.: 105 Ah

Motor power traction

Min.: 0.65 kW
(0.884 hp)

Max.: 0.65 kW
(0.884 hp)

Motor power lifting

Min.: 2.2 kW
(2.991 hp)

Max.: 2.2 kW
(2.991 hp)

Travel speed

Min.: 4.5 km/h
(2.8 mph)

Max.: 5 km/h
(3.11 mph)

Lifting speed

Min.: 0.09 m/s
(0.295 ft/s)

Max.: 0.15 m/s
(0.492 ft/s)

Weight

Min.: 550 kg
(1,212.54 lb)

Max.: 550 kg
(1,212.54 lb)

Description

• 3-point design, improve the trucks'stability. Upper horizontal drive motor to make replacing driving wheel easier. • Offer the optional of height limit switch. With a slim leg design with narrow legs, steel fork wheel size 120X35mm, tailored to fit Australian pallet size. With small turning radius of 1343 mm, work efficiently and freely in the narrow space. • With height deceleration function, the travel speed will reduced by 50% if the mast lift up to one meter hight. • Built-in charger, easy to access to power supply. With an ergonomic design and a height of 1.3m, the Ruyi new handle provides comfortable and convenient usage. • Steel back cover, it is strong and not easy to broken. • 8MM Steel Mast, strong and durable.
