Straight-toothed gear 22400hubsteel
Add to favorites
Compare this product
Characteristics
- Teeth
- straight-toothed
- Configuration
- hub
- Material
- steel
Description
Spur gears in steel, toothing milled, straight teeth, engagement angle 20°
Material:
Steel 1.0503 (C45).
Version:
Milled toothing, straight teeth.
Engagement angle 20°, bright.
Note:
Up to 70 teeth with hub one side, from 72 teeth disc form. The spur gears have a centre or pilot hole.
On request:
Spur gears pre-bored with keyway.
Drawing reference:
Form A: with hub
Form B: without hub
