Intrusion detector AP-360B
motionPIRfor door

Intrusion detector - AP-360B - OPTEX SEC Division - motion / PIR / for door
Intrusion detector - AP-360B - OPTEX SEC Division - motion / PIR / for door
Intrusion detector - AP-360B - OPTEX SEC Division - motion / PIR / for door - image - 2
Add to favorites
Compare this product

Characteristics

Detected entity
motion, intrusion
Technology
PIR
Application
for door
Other characteristics
compact, ceiling-mounted

Description

Overview
  • Compact wired recessed ceiling PIR motion sensor for volumetric presence detection and building automation.


Key features
  • 360° volumetric detection for ceiling mounting
  • Recommended mounting height: 2.5–4.5 m
  • Recessed installation or 86-type box mount
  • Adjustable detection sensitivity and selectable alarm periods


Applications
  • Intrusion detection
  • Lighting control
  • Smart home and building automation in lobbies, offices and rooms


Technical specifications
  • Product Range: AP Series
  • Model Code: AP-360B(C)
  • Detection method: Passive infrared (PIR)
  • Detection coverage: ø6 m at mounting height 4.5 m
  • Detectable speed: 0.3–3.0 m/s
  • Sensitivity: 2.0℃ at 0.6 m/s (three selectable levels)
  • Power input: 9.5–16 V DC
  • Current draw: 12 V DC Stand-by: 11 mA, Max.: 13 mA
  • Alarm output: N.O./N.C., 28 V DC 200 mA max.
  • Trouble output (D.Q.): N.C., 28 V DC 100 mA max (contact opens when casing detached)
  • Anti-tamper output: N.O./N.C., 28 V DC 200 mA max.
  • LED indicator: Warm-up (blinking), Stand-by (off), Alarm (solid on)
  • Operating temperature: -20℃ to +50℃
  • Relative humidity: < 95% RH
  • Installation: Indoor recessed or 86-type box
  • Mounting height: 2.5–4.5 m
  • Weight: 50 g
  • Dimensions: 52 x 42.5 mm
