Impeller pump 2CB serieswaterwith electric motorsubmersible
Add to favorites
Compare this product
Characteristics
- Technology
- impeller
- Fluid
- water
- Operation
- with electric motor
- Priming
- submersible
- Mobility
- stationary
- Domain
- industrial
- Applications
- for industrial applications
- Voltage
- 400 V, 380 V
- Flow
Max.: 1,200 m³/h
(42,377.60007 ft³/h)Min.: 20 m³/h
(706.29333 ft³/h)- Pressure
6 bar, 11 bar
(87.023 psi, 159.542 psi)- Head
Max.: 97.6 m
(320'02" )Min.: 21 m
(68'10" )- Power
Max.: 22 kW
(29.91 hp)Min.: 1.5 kW
(2.04 hp)- Fluid temperature
Max.: 90 °C
(194 °F)Min.: 0 °C
(32 °F)- Length
Max.: 645 mm
(25 in)Min.: 328 mm
(13 in)- Width
Max.: 275 mm
(10.83 in)Min.: 180 mm
(7.09 in)- Height
Max.: 330 mm
(12.99 in)Min.: 228 mm
(8.98 in)- Weight
Max.: 94.5 kg
(208.34 lb)Min.: 15.5 kg
(34.17 lb)
Description
Two impeller centrifugal pumps pressurisation systems for civil and industrial plants; the two opposed impellers guarantee high head with good delivery.
