Manual drum lifter DTP05-R500-SS

battery-poweredelectro-hydraulicmobile

Overview
The DTP05-R500-SS stainless steel corner drum lifter is constructed in 304-grade stainless steel with an adjustable drum gripper and a stainless steel sheave/plunger assembly. It is designed for safe handling of 50–220 L drums in food, pharmaceutical and cleanroom environments and for access at pallet corners and narrow pallet ends.

Features

• Corner-leg design allows access to drums at the corner of pallets (including 1200 x 1200 mm and 1200 x 1000 mm) and from the 800 mm narrow end of a Euro pallet.
• Adjustable universal drum catch to connect to steel tight-head, steel open-top, L-ring plastic, MAUSER and fibreboard drums.
• Height-adjustable gripper to handle a wide range of drum heights by repositioning the drum catch.
• Manual hydraulic hand pump (17 cc) for lifting and controlled lowering.
• Chemical-resistant elastic rubber wheels for reliable manoeuvrability in hygienic and corrosive environments.
• Optional ATEX 'Ex' certified variant for zones 1, 2, 21 and 22 with anti-static wheels, earthing chains and electrical continuity features.

Key details
Safe working load (SWL): 350 kg
Lift stroke / lift clearance: 500 mm (alternative figure: 420 mm)
Turning circle: 1260 mm
Unladen weight: 100 kg

Compatibility

• Designed for drums 50–220 L.
• Compatible with steel open-top, steel tight-head, L-ring plastic drums, MAUSER plastic drums and fibreboard drums.

Upgrades and options

• Electric-hydraulic push-button lift for higher throughput and reduced operator effort.
• Integrated battery-powered load-cell weighing system with accuracy to +/- 0.1 kg (zero and tare functions).
• ATEX-certified configuration for classified hazardous zones with required documentation and earthing arrangements.
• Custom attachments and adapters for non-standard drum styles (screw-top, bespoke pharmaceutical drums, etc.).

Documents
Technical drawings, full technical specification and instruction manual available for this model.

Technical specifications

• Model: DTP05-R500-SS
• Material: 304-grade stainless steel
• Safe working load (SWL): 350 kg
• Lift stroke / lift clearance: 500 mm (alternate: 420 mm)
• Drum sizes handled: 50–220 L
• Drum heights accommodated: approx. 380–1000 mm (height-adjustable gripper)
• Drum compatibility: steel open-top, steel tight-head, L-ring plastic, MAUSER plastic, fibreboard
• Pallet approach: corner of pallets including 1200 x 1200 mm and 1200 x 1000 mm; narrow end of Euro pallet 800 x 1200 mm
• Turning circle: 1260 mm
• Unladen weight: 100 kg
• Lift mechanism: manual hydraulic hand pump (17 cc)
• Optional features: electric-hydraulic lift, integrated weighing/load-cell (+/- 0.1 kg), ATEX 'Ex' variant, custom attachments
• Typical applications: food, pharmaceutical, cleanroom and other hygienic or corrosive-sensitive environments
• Warranty: standard 2-year manufacturer warranty
