Electric drum lifter DPC01-R500-SS

battery-poweredcounterbalancedwith gripping tool

Overview
This stainless steel counterbalance drum handler (model DPC01-R500-SS) is a powered drum lifter designed for safe, efficient handling of filled drums in regulated production environments such as pharmaceutical and food facilities. Constructed from 304-grade stainless steel and finished for hygienic cleaning, the unit eliminates manual lifting and allows precise placement onto pallets, bunds, conveyors and machines.

Key features

• Automatic beak gripper: clamps the drum top lip automatically, compatible with a wide range of drum lips; height adjustable.
• Battery-powered drive: two 180 Ah batteries with a 24 V, 1000 W electric drive wheel; rear tiller for drive and lift control; on-board smart 230 V charger with drive-disable function.
• Counterbalance design: no front legs — approach from any flat side; suitable for placing drums onto pallets, bunds, conveyors, machines and dollies; option for additional counterweight for heavier drums.
• Tiller controls: rear tiller with variable speed throttles, anti-trap protection switch and built-in horn; ergonomics and controls similar to mobile stacker trucks for rapid operator familiarisation.
• Drum compatibility: suitable for steel, plastic and fibreboard drums (100–220 litres, including MAUSER drums); automatic gripper requires some drum weight to close (not intended for empty drums).

Construction and finish
Manufactured from 304-grade stainless steel with aqua-blasted and vibro-polished components for a smooth, hygienic finish. Guarding provided in shatterproof clear polycarbonate for visibility and protection.

Optional features

• Tall-lift variant: increased lift stroke (option up to 760 mm) for loading into higher containment bunds or elevated equipment.

Technical specifications

• Model: DPC01-R500-SS
• Safe working load (SWL): 350 kg
• Drum compatibility: steel, plastic and fibreboard drums, 100–220 litres (including MAUSER drums)
• Drum gripping catch: automatic beak gripper, height adjustable
• Lift stroke: 500 mm
• Under-drum clearance: 320 mm
• Lifting system: electric-hydraulic lift via hydraulic pump and ram
• Front wheels: fixed 160 mm castors, aluminium-centred with polyurethane tyres
• Rear wheel: electric power drive wheel, 24 V, 1000 W
• Tiller drive control: rear tiller including lift control, emergency stop and anti-trap protection
• On-board charger: 230 V smart battery charger with drive-disable function
• Guarding: shatterproof clear polycarbonate
• Metal preparation: aqua blasted and vibro-polished stainless steel parts
• Surface finish: smooth, clean stainless steel
• Compliance: CE / UKCA
