Manual drum lifter DTP08-R1260-DR

hand-operatedhydraulichand crank

Overview
We have designed and manufactured this manual-hydraulic drum lifter dispenser to be suitable for decanting drums at low levels. The unit is fitted with a manual band assembly suitable for 120-220 litre drums. The manual crank handle allows the operator to rotate drums through 360° making it ideal for tipping from drum to drum or using a tap to dispense material.

Key product features

• Drum rotator (DR) attachment: Designed for decanting 120–220 litre steel and plastic drums. Fitted with a contoured band with rubber blocks to reduce drum slippage. Drum is secured using a dual ratchet and strap arrangement. Available lift strokes: 500mm, 760mm and 1260mm.
• Sideways rotation: Fitted with a slew-ring gearbox assembly allowing drums to be rotated sideways using a long stainless steel crank handle. Counterbalanced design with a small footprint. Gearbox provides a high ratio so rotation requires low operator force; gearbox remains mechanically locked when not being turned.
• Ergonomic height: Lifts drums to ergonomic working height for scooping or decanting, reducing bending and risk of back injury.
• Chemical-resistant wheels: High-quality elasticated rubber wheels with precision bearings for harsh environments. Rear-wheel tiller steering provides a tight turning circle; recommended for smooth surfaces.
• Manual hydraulic pump: Hand-assembled hydraulic systems; 13cc hand-operated pump with lowering valve. Pump raises a hydraulic ram which lifts a carriage via a zinc-coated lift chain. Pump handle designed for minimal force and precise lowering control.
• ATEX / UKEX option (optional): Fully certified variants available for use in hazardous/explosive atmospheres (zones 1, 2, 21 and 22). Units supplied with Declaration of Conformity and meet relevant directives and standards.

Optional features

• ATEX / UKEX option for zoned environments (zones 1, 2, 21, 22).
• 304-grade stainless-steel model suitable for clean rooms and GMP areas.

Notes
Manual rotation via crank handle allows fine control when decanting; drum compatibility includes steel, plastic and fibreboard drums (120–220 litres, including MAUSER drums). The unit is counterbalanced and designed to approach any flat side of a pallet (no legs in front of the lifter).

Technical specifications

• Model: DTP08-350kg-R1260-DR (Drum Lifter Dispenser)
  Model family: DTP08 series
  Typical safe working load (SWL): 350 kg
  Pallet approach: Approaches any flat side of a pallet, no legs in front of the lifter
  Drum compatibility: Steel, plastic and fibreboard drums, 120–220 litres (including MAUSER drums)
  Drum securing: Two 50 mm ratchets and webbing straps
  Drum rotation mechanism: Slew-ring horizontal gearbox assembly with long stainless steel crank-lever
  Lift stroke (example main config): 1260 mm (other strokes available: 500 mm, 760 mm)
  Under-drum clearance: 1080 mm
  Lifting system: Hydraulic 13 cc hand-operated pump with lowering valve; pump lifts a hydraulic ram which raises a carriage via a zinc-coated lift chain
  Guarding: Shatterproof clear polycarbonate (anti-static clear polycarbonate on ATEX variant)
  Metal preparation: Grit blasted mild steel; aqua blasted stainless steel parts
  Surface finish: Primer and polyester powder coated mild steel; stainless steel smooth and clean
  Unit colour: RAL 5010 (blue)
  Front wheel type: Fixed 160 mm with precision bearings
  Front wheel material: Aluminium-centred, polyurethane tyres (electrically conductive polyurethane tyres on ATEX variant)
  Rear wheel type: Outrigger 100 mm castors and rear 160 mm steerable wheel both with precision bearings
  Rear wheel material: Aluminium-centred, polyurethane tyres (electrically conductive on ATEX variant)
  Compliance: CE / UKCA (ATEX / UKEX compliance for certified variants; suitable for zones 1, 2, 21, 22)
• Model: DTP08-350kg-R1260-DR-Ex (ATEX / UKEX Drum Lifter Dispenser)
  Typical safe working load (SWL): 350 kg
  Pallet approach: Approaches any flat side of a pallet, no legs in front of the lifter
  Drum compatibility: Steel, plastic and fibreboard drums, 120–220 litres (including MAUSER drums)
  Drum securing: Two 50 mm ratchets and webbing straps
  Drum rotation mechanism: Slew-ring horizontal gearbox assembly with long stainless steel crank-lever
  Lift stroke: 1260 mm
  Under-drum clearance: 1080 mm
  Lifting system: Hydraulic 13 cc hand-operated pump with lowering valve; pump lifts a hydraulic ram which raises a carriage via a zinc-coated lift chain
  Guarding: Anti-static shatterproof clear polycarbonate
  Metal preparation: Grit blasted mild steel; aqua blasted stainless steel parts
  Surface finish: Primer and polyester powder coated mild steel; stainless steel smooth and clean
  Unit colour: RAL 5010 (blue)
  Wheels: Front fixed 160 mm and rear 160 mm steerable with electrically conductive polyurethane tyres where required; precision bearings
  ATEX features: Suitable for zones 1, 2, 21 and 22; electrical continuity considered and Declaration of Conformity supplied
  Compliance: CE / UKCA; ATEX / UKEX (zones 1, 2, 21, 22)
