Block ice production machine BIM3TCOS

for the food industry

Product Overview
The containerized block ice machine Tamutom BIM3TCOS produces 3,000 kg of high‑density block ice per day and integrates an on‑board cold room for immediate storage. The self-contained unit is engineered for continuous industrial use in fishing ports, seafood processing, meat and poultry plants, beverage production, fresh produce logistics and concrete cooling, reducing handling steps by combining production and storage on site. The integrated cold room maintains storage temperatures between -5°C and -10°C to limit melting and contamination.

Applications

• Fishing ports and coastal fishing fleets
• Seafood processors
• Meat and poultry plants
• Beverage producers
• Fresh produce logistics centers
• Concrete cooling and industrial cooling operations

Technical Information — BRINE TYPE (table data)
Total Ice Making Capacity: 3000 Kg /day
Ice Block Amount per Shift: 84 Blocks
Each Block Weight: 12 Kg (10cm*20cm*70cm)
Production Time per Shift: 7-8 Hours
Daily Block Production: 252 Pcs
Power Supply: 380-415 V, 3 Phase, 50-60Hz
Ice Temperature: Minus 12˚C
Refrigerant: Freon R404A
Unit Weight: 5000 Kg
Unit Dimensions: 40FT Standard Container
Power Consumption: 11,80 KW/h
Compressor Capacity: 15 HP
Condenser and Capacity: Air Condenser / 22740 M³/H
Type: 20FT Standard insulated container with sandwich panels
Cold Room Insulation: 100mm sandwich panels and cooling unit
Cold Room Dimensions: 300cm*200cm*250cm

Technical specifications

• Total Ice Making Capacity: 3000 Kg /day
• Ice Block Amount per Shift: 84 Blocks
• Each Block Weight: 12 Kg (10cm*20cm*70cm)
• Production Time per Shift: 7-8 Hours
• Daily Block Production: 252 Pcs
• Power Supply: 380-415 V, 3 Phase, 50-60Hz
• Ice Temperature: Minus 12˚C
• Refrigerant: Freon R404A
• Unit Weight: 5000 Kg
• Unit Dimensions: 40FT Standard Container
• Power Consumption: 11,80 KW/h
• Compressor Capacity: 15 HP
• Condenser and Capacity: Air Condenser / 22740 M³/H
• Type: 20FT Standard insulated container with sandwich panels
• Cold Room Insulation: 100mm sandwich panels and cooling unit
• Cold Room Dimensions: 300cm*200cm*250cm
