High power density DC/DC converter TPS150-PMD24S

isolatedprinted circuitindustrial

The TPS150-PMD24S is the high-power 150W model in the TPS030-150W series of isolated DC-DC power modules, designed to deliver efficient and reliable power for the most demanding applications. This module accepts a wide input voltage range of 9-75 VDC and provides a stable 24V output, capable of delivering up to 6.2A of current. It achieves an impressive efficiency of up to 89%, ensuring optimal power conversion and minimal thermal loss. The module is built with robust 1500 VDC isolation between input and output, guaranteeing system safety and noise immunity. It incorporates a full suite of protection features including input under-voltage lockout, over-temperature, over-voltage, and over-current protection. For system integration flexibility, it offers positive logic remote on/off control and an external output voltage trim function with a ±10% adjustment range. Housed in a larger industry-standard package to handle the high power density, the TPS150-PMD24S is the ultimate power solution for high-performance industrial automation, telecom infrastructure, precision measuring instruments, and rugged military systems. Key Features Premium Efficiency: Achieves up to 89% efficiency, minimizing energy waste and heat generation. Enhanced Safety Isolation: Features 1500 VDC minimum isolation (Input/Output, Input/Case, Output/Case) for maximum safety and noise rejection. Comprehensive Protection Suite: Includes under-voltage lockout (power up at 9V, down at 7.5V), over-temperature shutdown, over-voltage protection (115-140% trip range), and over-current limit (105-200%).
