Chain stitch sewing machine TITAN 3200

single-needlesingle-threadfixed

Overview
Right- and lefthand fringing machines that produce decorative fringe on both sides of carpets, shawls and house linen. Designed for inline integration in automated production lines; the TITAN 3200 series delivers simultaneous double-side fringing from a single thread, reducing handling and increasing throughput.

Technical highlights

• Speed: 800 spm (standard model); 3200 variant: 1200 stitches per minute for high-speed cut fringes
• Maximum material thickness: 10 mm
• Stitch width: 10 mm
• Needles: 1

Always included

• RPE/2200: external stitch adjuster
• EPF/2200: pneumatic fringe ejector (requires 4–6 bar air pressure)

Options

• CP/2200: pneumatic pressure foot lifter

Remarks

• Available in right- and left-hand versions for line configuration
• 2200C: chain stitch backing with cut fringes
• 2200NC: cut or non-cut fringe variants
• 3200: high-speed variant providing cut fringes at 1200 stitches/min

Technical specifications

• Model: TITAN 3200
• Machine type: Right- and lefthand fringing machine (simultaneous double-side fringing)
• Application: Decorative fringe on carpets, shawls and house linen, from a single thread
• Speed: 800 spm (standard); 3200 variant: 1200 stitches/min (high-speed cut fringes)
• Maximum material thickness: 10 mm
• Stitch width: 10 mm
• Number of needles: 1
• Included accessories: RPE/2200 (external stitch adjuster), EPF/2200 (pneumatic fringe ejector — requires 4–6 bar)
• Optional accessories: CP/2200 (pneumatic pressure foot lifter)
• Variants: Right and left versions; 2200C, 2200NC, 3200
