Monitoring control system PCS FS

regulatingfor dosinglevel

Overview
The PCS FS is ROJ's control system for pneumatic and mechanical seed drills. The solution is based on the Agri-Motion DMD-0 drive motor and is managed by the PCS 100 ECU. The architecture is modular and scalable to support additional seed distributor units and fertilizer hopper distributors.

Key features

• Support for up to 4 motor groups with independent settings
• Easy-to-use touch screen interface for in-cab operation
• On-the-move adjustment of seed rates from the tractor cab
• Distributor priming function
• Calibration and seed test procedures
• Partial and total hectare counters
• Seed level monitoring
• Electronic pressure sensor with high/low pressure warnings
• Tramline function for headland/isolation rows
• USB export of seeding job logs for billing and statistical analysis

System architecture
The system integrates Agri-Motion DMD-0 motor(s) controlled by the PCS 100 ECU. The modular design enables installation of additional seed distributors and fertilizer hopper distributors to adapt to different machine configurations and farm requirements.

Technical specifications

• Product type: Control system for pneumatic and mechanical seed drills
• Primary drive: Agri-Motion DMD-0
• Controller: PCS 100 ECU
• Motor groups: Up to 4 groups, independently configurable
• User interface: Touch screen for control and parameter changes
• Rate adjustment: In-cab adjustment of seed quantity
• Distributor functions: Priming, calibration and seed test
• Counters: Partial and total hectare counters
• Monitoring: Seed level monitoring
• Pressure sensing: Electronic sensor with high/low warnings
• Field functions: Tramline support
• Data logging: USB export for job logging, billing and analysis
• Expandable: Supports adding seed distributor units and fertilizer hopper distributors
