Overview
The NIV pneumatic ship unloader series are suction-type bulk handling units designed for large-scale ship discharge. Each unit integrates a machine room (mechanical components) and a tubular lattice boom that supports the suction pipes, mounted on a rotating slewing ring to position the pipes over the ship hold. Material is conveyed to the centre of the slewing ring and filtration is provided by a large self-cleaning filter unit.

Key features

• Customizable
  • Fully configurable to customer requirements and site constraints
  • Mounting options: fixed gantry, rail-mounted gantry, gantry on rubber wheels, on tyres/wheels
  • Low dust and noise emission options
  • Various flowrates to suit vessel sizes and discharge targets
  • Discharge interfaces: trucks, conveyors, wagons
  • Wide range of accessories and site-specific adaptations

• Simple and heavy-duty construction
  • High wear‑resistant alloys for airlock and unloading piping
  • Low-turbulence hydraulic design with reduced pressure drop via optimized elbow geometry
  • Designed for multi-million ton throughput in standard conditions

• Low dust emission
  • Self-cleaning filter with compressed‑air jet‑pulse system (filter area 68–400 m²) with no moving parts in the filter element
  • Options suitable for operation in urban or sensitive environments

• Low energy consumption
  • Direct‑drive turbo‑blower with inverter regulation for optimized energy use
  • Real multi‑stage turbo‑blower with aeronautic design for improved performance
  • VIGAN airlock for sealed product exhaust and minimal losses
  • Optimized unloading piping to limit pressure losses

• Hydraulic boom
  • Safe, reliable hydraulic system for lifting/withdrawing the boom from the vessel
  • Boom capable of lifting a skid‑steer loader for maintenance and handling tasks

• Safe by design
  • Includes ATEX study, risk analysis and CE documentation in the standard design package
  • Safety achieved through mechanical design principles without reliance on complex electronics
  • Site-specific engineering for wind, seismic and other local constraints

• Best efficiency
  • High unloading efficiency with limited capacity reduction during vessel cleaning compared with nominal capacity

References / Typical installations

• Casablanca, Morocco – NIV 800 tph / 750 kW on rails (2017)
• Rio de Janeiro, Brazil – Two NIV 300 tph / 250 kW on rails (2018)
• Port Sudan, Sudan – NIV 600 tph / 500 kW with gantry on rubber wheels (2015)
• Dunkerque, France – NIV 600 tph / 500 kW on gantry on rails (2017)
• Calaca, Philippines – Two NIV 600 tph / 500 kW on gantry on rails (2017)
• Yanbu, Saudi Arabia – Two NIV 500 tph / 400 kW with gantry on rails (2021)
• Taichung, Taiwan – NIV 500 tph / 400 kW with gantry on rails (2020)
• Chattogram, Bangladesh – NIV 200 tph / 160 kW with gantry on rails (2021)
• Durban Port, South Africa – Two NIV 600 tph / 500 kW with gantry on rails (2022)

Characteristics / Technical specifications

• Product series: NIV
• Equipment type: Pneumatic ship unloader (suction-type)
• Main components: machine room (mechanical elements), tubular lattice boom, suction pipes, rotating slewing ring, large self‑cleaning filter
• Filter area range: 68–400 m² (jet‑pulse system, no moving parts)
• Typical capacities: 200–800 tph depending on configuration
• Typical motor powers: 160–750 kW depending on capacity
• Installation configurations: on rails, gantry on rails, gantry on rubber wheels, fixed gantry, on tyres/wheels
• Materials & wear protection: high wear‑resistant alloys for airlock and unloading piping
• Air handling: direct‑drive turbo‑blower, multi‑stage aeronautic design, inverter energy regulation
• Sealing & exhaust: VIGAN airlock for sealed product exhaust
• Design life/performance: sized for multi‑million ton throughput
• Safety & compliance: ATEX study, risk analysis and CE documentation included; site‑specific design for wind/earthquake
