High power density DC/DC converter

regulatedisolatedSMD

Product family
Member of the PRM® Regulator family: MPRM28AF360M120A00. FULL ChiP package with surface-mount and through-hole options for high-density power conversion in military and industrial applications.

Summary
The MPRM28AF360M120A00 is a ZVS buck-boost PRM® regulator delivering up to 200 W in a low-profile FULL ChiP package. It supports pick & place / SMD assembly, is available in full- and half-chip configurations for flexible topologies, and meets military input voltage and transient requirements.

Product features

• ZVS buck-boost topology
• High efficiency and high power density
• Approx. 1 MHz switching frequency
• Very low profile FULL ChiP package
• Pick & place / SMD compatible; J-Lead mounting option
• Surface-mount or through-hole package options
• Mix-and-match full and half-chip configurations
• Meets MIL-STD-1275 and MIL-STD-704

Pricing (MSRP)
Quantity: 25+ — $193.21
Quantity: 100+ — $181.22

Reference materials included on product page

• Product-specific Data Sheet
• Application notes for VI Chip / PRM family
• White papers on factorized power architecture and fixed‑ratio converters
• Safety approvals and certificates for PRM family

Packaging / mechanical
FULL ChiP package — 1.28 x 0.866 x 0.265 in / 32.5 x 22.0 x 6.73 mm

Technical specifications

• Part Number: MPRM28AF360M120A00
• Designation: PRM® Regulator
• Input Voltage (nominal): 28 V
• Output Voltage (nominal): 36 V
• Output Power: 200 W
• Package: FULL ChiP (surface-mount; J-Lead option)
• Mounting Style: J-Lead (option shown)
• Product Grade / Temperature: M = -55°C to 125°C
• Minimum Order Quantity: 25
• Lead time (as shown): 40 weeks
• Key compliance: Meets MIL-STD-1275 and MIL-STD-704; multiple safety approvals listed for PRM family
