Resistive touch screen monitor R06L200-CHA1OD

with touchscreen6.5"640 x 480

Key Features

• Sunlight-readable high-brightness panel (700 nits)
• Resistive touch screen (default); optional protection glass without touch
• VESA mount support
• Operating temperature: -10°C to 60°C (standard); optional -25°C to 60°C with heater
• Optional UV film for solar radiation protection in direct-sun environments
• Metal enclosure with fanless design

Overview
The R06L200-CHA1OD is a 6.5-inch resistive touch chassis display designed for industrial outdoor and harsh-environment applications. Its sunlight-readable 700-nit panel and optional UV protection make it suitable for installations exposed to direct sunlight. VESA-compatible mounting and a metal enclosure simplify integration into control cabinets, kiosks and machinery panels.

Display Specifications

• Size: 6.5 inches
• Resolution: 640 x 480
• Panel Brightness: 700 nits
• Contrast Ratio: 600:1
• View Angles: 80° / 80° / 70° / 70°
• Display Color: 16.2M
• Active Area: 132.48 x 99.36 mm

Environment

• Operating Humidity: 10% to 90% RH, non-condensing
• Operating Temperature: -10°C to 60°C (standard); optional -25°C to 60°C with heater
• Storage Temperature: -20°C to 70°C

Certification

• CE
• FCC

I/O Ports

• USB: 1 x USB for touch interface
• Video: 1 x VGA (default); HDMI and DVI optional
• Audio: audio line-in (3.5 mm) optional; 2 x speakers optional

Mechanical

• Dimensions: 200 x 149 x 45 mm
• Mounting: VESA mount
• Enclosure: Metal
• Cooling: Fanless design

Accessories

• 1 x VGA cable
• 1 x HDMI cable
• 100–240V AC to DC adapter
• Power cord
• Manual
• VESA screws (varies by product)
• Optional: Remote controller (varies by product)

Power

• Power input: 12V DC in

Control

• Buttons: 5 keys ( -, +, Power, Esc, Enter )

Technical Specifications

• Model: R06L200-CHA1OD
• Product type: 6.5-inch resistive touch chassis display
• Certifications: CE, FCC
