LCD monitor R10L210-MRM2

resistive touch screenmarine10.4"

Overview
Winmate R10L210-MRM2 is a 10.4" marine display certified to DNVGL-CG-0339, IEC60945 (4th) and IACS E10 for reliable operation in harsh maritime environments. Rugged mechanical design, fanless cooling and in-house reliability testing ensure stable performance for mission-critical shipboard applications.

Key Features

• 10.4" 800 × 600 resolution marine display
• Resistive touch screen (optional AR protection glass without touch)
• IP66 aluminum front housing with powder coating (rear IP54)
• 24 V DC input via terminal block (9–36 V DC acceptable)
• Picture-in-picture (PIP) and multiple video inputs
• Front-panel OSD controls and dimming knob (near 0%–100%)
• Enhanced shock and vibration resistance, fanless design

Product Details
Designed for continuous shipboard use, the display meets international marine regulatory requirements and passes rigorous in-house reliability tests. Hyper-dimming with a front knob allows linear backlight control from nearly 0% to 100%; an optional transflective film improves sunlight readability. Front OSD, PIP and easy access controls simplify monitoring and switching between multiple input sources. Robust metal housing, high power efficiency and low heat dissipation support long-term operation in maritime conditions.

Certifications

• DNVGL-CG-0339
• IEC60945 (4th)
• IACS E10
• CE
• FCC

Accessories

• Included: user manual, DVI cable, VGA cable, RS232 serial cable, S-Video cable, composite cable
• Optional: Marine Mounting Kit MMK-104 (Part No. 99KK10400010)

Technical specifications

• Model: R10L210-MRM2
• Display size: 10.4 inches
• Resolution: 800 × 600
• Touch / Glass: Resistive touch (default); AR glass optional
• Brightness: 600 nits
• Contrast ratio: 400:1
• Viewing angles: 70/70/70/60
• Colors: 262K
• Active area: 211.2 × 158.4 mm
• Operating humidity: 5%–95%
• Operating temperature: -15 ~ 55 °C
• Shock: 15G, 11 ms
• Vibration: 0.7g @ DNV-CG-0339 (Class A)
• IP rating: IP66 front / IP54 rear
• Serial ports: 1 × RS232 (remote), 1 × RS232/USB (touch)
• Video inputs: VGA, DVI-D, Composite, S-Video
• Dimensions: 339 × 256 × 72 mm
• Cut out: 300 × 232 mm
• Weight: 3.7 kg
• Mounting: VESA / panel mount
• Enclosure: metal housing with aluminum bezel
• Cooling: fanless
• Power: 24 V DC-in with isolation (certified); 9–36 V DC acceptable
• Power consumption: 25 W (typical)
