Permanent electro-magnetic clamping of moulds on injection mould presses adapted to all sizes and shapes of mould.
STÄUBLI offers a complete range of products serving the PLASTICS INDUSTRY including:
- quick mould clamping,
- quick connection of services using quick-release couplings and multi-couplings,
- automatic ejector hook-up,
suitable for all methods of mould changing: vertical or horizontal loading and existing or new machines.
|
|
|
|
|
|
Quad-Press: A magnetically clamped mold is subject to neither deformations nor to inner tensions.
The force is distributed uniformly throughout the contact area, instead of only being applied on the external edges of the base-plate, as it happens when traditional clamping methods are used.
The quality of the molded part is constant in time.
Each 80HC square pole generates a constant, predictable and concentrated force of 1000 kg.
This force improves the performances to an unbeatable level, giving a greater available force in a smaller contact area.
Lead time is strongly reduced; now the SMED production is a reality.
Moulds of any size, even bigger than the machine plates are easily clamped with no modification.
Quad-Press is maintenance free, due to it doesn't present any mechanical component inside.
The new IPC system is available on request with the touch-screen device.
IPC follows step-by-step the machine operator during mold change procedure and give in real-time the actual clamping force generated on the mold.
|
|
|
|
|
|
HotMAG
permanent electro magnetic system for quick clamping of high temperature moulds.
The new permanent electro magnetic system HotMag is the final answer to all the needs to make quick change operations on press machines working with high temperature moulds.
The innovative magnetic circuit, made of special solenoids and high energy permanent magnets, allows to
operate with temperature up to 250° C. (482 ‘F).
The full metallic surface allows the perfect stability and uniformity of clamping all over the contact area
granting high performances in the long run.
Quick: Few seconds only to activate and deactivate the system. Simply pushing a button!
Ergonomic: The operator that can remain always at a distance from the mould. No risk!
Easy and practical: No modification to the machine, no modification to the moulds and no special tools are required.
Time saving: The mould can be preheated outside the machine with a great advantages!
Safe: Only the high strength generated by the permanent magnets will hold the mould at indefinite period of time.
Convenient: The low investment and the high efficiency grants a quick pay back.
|
|
| ... products without technical information |
| |
The Alpha Mill Round Milling Chuck is a Permanent-Electro Magnetic System—it requires electricity for just a fraction of a second to polarize the magnets contained within the chuck.
No electricity is required to maintain the magnetism and is therefore "failsafe." The Alpha Mill Round provides significant magnetic clamp force for milling, drilling, tapping and other machining processes, while managing the magnetic flux.
Perfect for :
- Job Shops, Mold Shops or Production Machining
- Squaring Up
- Five Face Machining
- Thru Machining
- Pallet Applications
- Large Plate or block Applications
|
|
|
|
|
|
The Alpha Bi-Polar (ABP) has grown out of the need of many customers desire to hold bar stock, both flat and round. The ABP allows the user to have complete access to the top of the part without straps interfering with the process and reduces set up considerably.
- Available in 220 and 440-480 volts.
- Rigid steel and brass construction for better accuracy and longer life.
- Individual pole extenders can be utilized to raise a part off the magnetic chuck surface for through hole work and to adapt to varying diameter bars.
- Self Shimming pole extenders-Capable of holding parts with stepped diameters
- Permanent Electro-does not require electricity to maintain the magnetic field.
- Up to 0.250" of resurfacing capabilities on the magnet face.
- Magnetic clamping reduces vibration and increases tool life.
- Alpha's controllers are equipped with circuit breakers and can be integrated into a machines PLC.
- Magnetically balanced, each pole contains equal amounts of north and south magnetic flux to eliminate stray flux and to simplify pole placement.
- Available Accessories
- Pole extenders-used to raise a part off the surface of the magnet and vary the diameter range
- Self Shimming pole extenders
|
|
The Eagle Lift® utilizes state of the art technology to make a powerful, lightweight permanent lifting magnet. Our exclusive Test Talon® feature allows an operator to safely test load feasibility and a deep "V" notch between the pole shoes allows greater stability when lifting round stock.
- Permanent Magnet; does NOT require electricity
- Smooth Lever Action between Off & On positions
- Bi-Polar capabilities enable the unit to lift both flat and round stock safely
- Safety factors exceeding industry standards
- Single hand operation
- Very little residual magnetism at OFF makes lifter positioning easier
- Portable, compact and lightweight
- 3 Year Warranty
- Made in the USA
|
|
|
|
