Automatic vertical & orizontal packaging machines
- Built for mailing
- Cost savings by using film
- Safer way of mailing
- High performances & low consumption (from 1200 to 3000 pcs/hour)
|
|
The CONTINUA is a completely automatic horizontal packaging machine, extremely compact and with an innovate sealing system (worldwide patented). The products, placed with insuitably adjustedside guides, are driven into a forming box by a couploe of pusher, while the central sealing is carried out by a heated wheel. The film wrapping the products runs on a loose conveyor belt driven by two pliers that, trought an alternate movement, seal and cut the film trasversally. Bags are then ejected throughan opening at the end of the machine.
ADVANTAGES :
- Use of flat film – great saving on Film
- Small investment for a high performance machine
- Automatic feeder for magazines, CD’s and DVD’s
- User friendly and energy – saving
- Quick job changeover
- Films which can be used: PE, polyolephine films, PP.
|
|
SKINETTA case packaging products include pneumatic and servo-mechanically driven machines:
- Sideloader
- Toploader
- Wrap-Around Packer
- Tray Packer
- Tray erectors with and without tray loading
|
|
A wide range of machines made of stainless steel AISI 304 according to CE normatives and are equipped with a volumetric electronic sensor to constantly control vacuum and gas packaging. Vacuum cycle can be excluded and, thanks to the 'soft-air' device, it is possible to control air immission in the chamber. A digital, low supplied control panel is equipped with 5 programs to memorize. High density polyethilene plates to reduce chamber volume are supplied with the machine. Upon request, machines can be assembled with a tilting device for liquid products. Gas injection system (optional).
|
|
Automatic packing machine
IMB AUT 240 COMKPACT, have been projected and built keeping in mind of the various typologies of feeding you roll that are set in the cycles of job.
The versatility of this machine allows him to be set in direct exit to the checker as unity of line to different Checkers or fed by tables of accumulation in automatic.
The machine is managed by PLC and it is able to manage the introduction and clearing you roll in various stations of unloading.
- Structure to closet with integral protection
of the mechanical and electronic parts
- Ample range ø rolls up to ø500 mm
- Cutter film-fabric with electric blade hidden
- Every type of polythene, both transparent and coloured,
according to optional features, can be used
- Control microprocessor with trouble-shooting feature
- Output capacity up to 40÷80 rolls/h
- Longitudinal Welding by Thermo-fusion
- Edge-Closing by thermo-retraction with hot-air
- Possibility to wind more turns of polyethylene on the roll
|
|
|
|
|
|
- The fabric roll are passed into the machine through belt conveyer system..
- Fabric Roll ready for packing is pushed from belt conveyer for wrapping by a pneumatically operated plate. The fabric roll gets wrapped by polythene sheet in the process and is ready for width wise sealing..
- The width wise sealing and cutting of the fabric roll is done by the vertical movement of top sealing bar which completes the warping of polythene on the fabric roll and also performs width sealing of the polythene sheet.
- Once the width wise sealing is complete, the roll is moved forward to the side sealing assembly.
- The polythene ends on either sides of the roll are pulled together for proper side sealing and cutting by suction pumps.
- Pneumatic operated side sealing bars perform the side sealing and cutting of the extra polythene thus completing the basic packing operations.
- The sealing bars have special sealing and cutting wires running across them that are automatically heated at the time of sealing and cutting operations.
- On the completion of side sealing, the packed fabric roll is transferred to a heat chamber so as to crimp the polythene tightly over the fabric roll. This ensures packing without air gatps in the rolls.
- The complete system is PLC controlled and the electricals are placed inside a separate box for the convenience of the operator and the maintenance staff.
|
|
Automatic packing machine
IMB A, have been projected and built keeping in mind of the various typologies of feeding you roll that are set in the cycles of job.
The versatility of this machine allows him to be set in direct exit to the checker as unity of line to different Checkers or fed by tables of accumulation in automatic.
The machine is managed by PLC and it is able to manage the introduction and clearing you roll in various stations of unloading.
- Structure to closet with integral protection
of the mechanical and electronic parts
- Ample range ø rolls up to ø1300 mm
- Cutter film-fabric with electric blade hidden
- Every type of polythene, both transparent and coloured,
according to optional features, can be used
- Control microprocessor with trouble-shooting feature
- Output capacity up to 60÷100 rolls/h
- Longitudinal Welding by Thermo-fusion
- Edge-Closing by thermo-retraction with hot-air
- Possibility to wind more turns of polyethylene on the roll
|
|
|
|
|
|
Automatic high-performance film wrapper "Delta 2000"
Automatic film wrapper for wrapping loosely stacked newspapers and magazines in PE film.
Special customer benefit:
• The packages withdraw the upper film from the film magazine
with minimal force. The stacks do not fan out
• The lower film is delivered in sync with package conveyance. The
film supplied is just sufficient for the present package
• Lateral welding can be integrated. You do not require a second
machine, which takes up space. The unit can be retrofitted as
optional equipment and does not reduce the capacity of the
machine
• Servo drive for welding unit with very fast and accurate motion
sequences. The film welding seam is easy to reproduce
• Frequency-controlled transport. Machine can easily be integrated
into existing lines
• Operation via Touchscreen, machine status and faults on plain
text display
• The operator only has to look after the buttons which he needs for the current machine status.
• Low-maintenance design. Low operating costs.
|
|
# ALTERNATE OR CONTINUOUS DUTY
# USING PRE-GLUED
# BOXES OR FLAT BLANKS BOX CLOSURE BY GLUE OR JOINTS
|
|
Sugarpack
RS20 Special, automatic packaging machine starting from paper or paper-based pre-made bags.
It fills and closes paket shape bags: 45-55 ppm for 1 kg. of sugar or similar products. Easy size changeover.
Very economic and efficient line, ideal for making high quality bags at a very good quality/price relation.
|
|
Shuttle welder with output power starting from 4 up to 20kW with two work tables gliding on rails (pneumatic or manual) may be used in many industries for welding/molding elements made of PVC. It is also great machine for blister packing.
It has two (2) workstations allowing for simultaneous work of two operators or much efficient work cycle by one operator.
Custom designed tooling (electrodes) provides aesthetic and durable weld during production cycle.
The machine has two separate temperature sensors for problem free and efficient working conditions of the RF generator. It has programmable PLC steering, fast and efficient antiflash system and it's fully CE compliant.
medical and healthcare equipment
advertising and promotion
safety clothing
office accessories
blisters
-----------------------------------------------
zgrzewarki, wykrawarki, formierki
hf welders, rf welders, roller die cutters
Stretch ceiling machines, Zemat TG
-----------------------------------------------
|
|
Automatic filling and wrapping machine for foiling butter, margarine, melted meat, cottage cheese, fresh cheese, ice-creams, edible fats, lard etc into aluminum foil laminates or parchment paper.
Size of packages:
500g- 135x80x50 mm
200(250)g- 100x75x29(37)mm
100(125)g- 75x50x29(37)mm
Custom weight and size optional (dosing range 50g till 500g)
*maximum output capacity- 80 bricks/min
*machine size- 2900x2490x1750 mm
*machine weight- 1425 kg
|
|
Automatic packaging machine is designed for foiling of processed cheese with aluminum foil. Tear-strip applicator is installed on the machine.
Dose mass of product: 30g; 62,5g; 100g
Dimensions of briquette: 30g-50x50x12mm; 62,5g-50x50x24mm;
100g-71x52x26mm;
Technical characteristics:
*maximum output capacity- 65 bricks/min
*dimensions- 2800x1510x1700 mm
*weight- 1500 kg
|
|
|
New generation of well known Blisterflex thermoformer, in high productivity version and GMP design. Very low maintenance. Raised efficiency and extremely versatile, produces blisters in the combinations of traditional materials PVC/ALU, PVDC/ALU, ACLAR/ALU, as well as ALU/ALU.
|
|
|
|
|
|
The Formpack models F4 and F5 are thermoforming machines able to satisfy both medium and high production requirements, depending on the different kinds of customization.
The main features of both models are as follows:
- They can be used with a wide variety of thermoform films, including flexible, rigid and foamed materials. All standard sealing materials such as plastic, medical paper and tyvec can be used.
- The F4 and F5 machines are available in both seal-only format and vacuum-gas format for producing vacuum, MAP and skin packs.
- The machines can be customized regards the length of frame, the mould motion, the thermoforming system, the loading area, the number and type of cutting stations.
- Both models are suitable for working in damp, aggressive environments as the chassis, all protection covers and bearings are made from stainless steel and the machine is IP65 rated.
- No external lubrication is required.
- Colour touch-screen with error diagnostic function. It can also display the electric and pneumatic schemes and some basic instructions.
- Changeover with quick release
- Other options include shape cutting, printed top web, coding units, in-line printing and labelling systems, in-line dosing/filling systems.
|
|
Single station High Frequency ZDPS welder 3-10kW. You may weld PVC and PET-G materials with this machine. Because of small size it is very easy to move it from one place to the other and it doesn't take much space on your production hall.
This model has preheated welding platen which helps to get high quality welds. Machine is fully shielded which protects operator from harming radiation effects.
Main features:
+ Ergonomic working space
+ Easy in use
+ Possibility of saving 30 welding programs in PC
+ Modern Mitsubishi steering controls
+ Fully shielded and CE certified
Perfect tool for production in:
+ packaging industry
+ advertisement industry
+ medical equipment
+ cloth industry
+ office accessories
|
|
EASY FORM
EASYFORM is an in-line thermofor-ming machine with a compactdesign, completely made of AISI304 stainless steel and anodizedaluminium with IP 65 protection class. It is suitable for small andmedium productions.
This model, thanks to high versa-tility, can be applied in food, indu-strial and medical field.
The machine can work with bothflexible and rigid material
It is available in two versions:EASYFORM N for sealing only and EASYFORM VG for vacuum packaging and vacuum/gas packaging.
The machine can be easily washed; it is ideal to work in aggressive and damp environ-ments
The changeover is quick and easy, The supplied brushless motorgrants high precision and speed This machine can be customized with several options such as prin-ted top web, coding units,dosing systems, slicers, in lineflexographic printer, as well as obtain the “Europe hole“ in blister packaging.
|
|
The MSK shrink frame technique ensures targeted and metered generation of heat without flames. The optimum shrinking temperature ensures gentle warming of the film which retains its tensile force and fatigue strength. The heating systems developed by MSK are matched to the varying requirements of different industries.
|
|
Large-format sleeve wrapper with shrink tunnel
SUPER WRAP 1300 de Luxe In-Line
Furniture and shelf components, construction and insulating materials, multi-package bundles, and much more.
The large format sleevewrapper Super Wrap 1300 de Luxe In-Line and the shrink tunnel Universal 1300 NT with HV technology: this combination makes total closure transportation packaging possible, and does away with the need for additional fusion or sealing tools.
The innovative HV technology of the shrink tunnel is responsible for controlled overlapping and adhesion of the excess side film, without touching the product.
|
|
FALCON is a horizontal flow-wrap type packaging machine which produces packs sealed on three sides from a roll of heat-sealable film.
Perfect for rapid and frequent set-up changes without compromising high-speed packaging (max 200 mechanical cycles per minute).
Packages products in the foodstuffs sector, the cosmetics sector, the pharmaceutical sector and the stationery sector.
Cantilever construction. Packaging speed: up to 200 packs/min (300 packs/min for the special version).
|
|
|
Full servo horizontal pillow pack wrapper to obtain pillow pack style packs from a flat reel of heat/cold sealable wrapping material. Cantilevered contruction. PEARL is manufactured without mechanical drives: drive motors are connected directly to the various assemblies. The electrical panel is housed inside the machine frame and protected from external environment. PEARL reaches up to 120 cycles/min, capable of wrapping diferrent products in food and non food sectors.
|
|
|
Horizontal flow wrap, entry level machine with rotary crimp jaws, designed to wrap at speeds of up to 100 bags per minute. An extremely versatile, compact and reliable machine, the Swift will accomodate a wide range of food and non-food products.
|
|
|
GHIBLI is a high-speed packaging for large products and irregular shapes. GHIBLI: horizontal flow-wrap type packaging machine for producing packs sealed on three sides from a roll of heat-sealable packaging film. Ghibli is an LVA, Servo, Long Dwell (cantilevered box-motion) machine
|
|
|
SHAMAL is a horizontal flow wrap type packaging machine that produces pillow bag in air-tight form as well with three seals originating from a wrapping material sealer reel. SAMAL has also been design for M.A.P (Modified Atmosphere Packaging). High flexibility: the format can be changed in just a few minutes. Aesthetically perfect packs. Easy to clean and sanitized: cantilevered concept and stainless AISI 304. Packaging speeds: up to 70 packages per minute in M.A.P.
|
|
The Vetta is a Form Fill Seal machine that separates itself from the rest of the pack by offering "multiple bag style" varieties and the versatility of many machines in one system.
- The Vetta can offer up to 20 different bag styles, from standard vertical form fill and seal using clear or printed film, to stand-up oval bottom bags with sombrero hole punch, "all on one machine".
- The Vetta uses the latest technology, allowing zipper integration and our patented resealable tab and/or reclosable adhesive strip options.
|
|
|
|
|
|
Small footprint, high flexibility
Over 600 Noack DPN760 machines in operation worldwide are proof of the confidence users in ethical, generics and contract sector place in Noack technology. The flexibility of the intermittent motion Noack DPN760 provides both operation in a standalone basis, as well as integration with the cartoner, such as a Promatic P91 horizontal cartoning machine.
As a compact, entry-level solution, it is ideal to start-up operations buth also offers a number of upgrade options to increase productivity. Its proven technology has been continually enhanced to serve the changing needs of the marketplace, established the next generation DPN760 as a key choice within the contract and generic markets, where fast changeover, reliability and high utilization are essential.
Key advantages
- Quick changeover thanks to latest servo technology, format parts with quick release, light-weight format parts and electronically stored format parameters
- Processes all common thermoformable films
- Established and successful experience with alu cold forming
- Powerful PLC with operator friendly touch panel
- Upgrade options include automatic feeding systems, filling inspection and ejection station, in-line foil printer, print mark registration and complete line with Promatic cartoner
- All Noack format parts will be tested and optinized on one of our dedicated test machines
|
|
Blister machine UPS 1040
Universal and highly successful blister machine in the medium to high-speed category with intermittent platen sealing.
- Intermittent web index with platen sealing and multi-stroke punching
- Machine adjustment at the touch of a button
- Two-and-three-lane operation with up to 60 forming cycles/minute and 200 punching cycles
- Output of up to 600 blisters/min
- As an intermittent-motion machine ideal for the production of alu/alu blisters, large blisters with stiffening ribs, calendar packs etc.
|
|
|
|
|
|
With know-how and innovation we have developed blister lines for in-line production of blister packages where future-oriented and innovative technologies are used.
If simple carton standard blisters or environmental-friendly mono-material packs with fully recyclable blisters or soft film blisters for medical use or high-quality 3D-blisters with superior design or Tyvek blisters or …
One of our fully automatic blister lines with numerous integration and extension possibilities will always fulfill your demands.
KOCH blister line KBS-KF
Blister line for large blisters with cover film of different materials.
The blister line KBS-KF - for in-line production of mono-material blister packs with cover film: absolutely trouble-free. In the choice of format and in the choice of materials that will be used for the blister packs. PE, PET, PVC, Tyvek, aluminum or lot of other materials.
Advantages of this machine technology
- Very high cycle rate
- Low tool costs, as no pallets or tool carriers are required
- Quick change-over
- Very quiet because various servo-motor drives
- Easily to service due to modular construction and modern machine design
- Latest PC technology with operator convenient control via 15“ touch screen
- Remote diagnostics via internet or modem
|
|
These machines are designed for industries that use blisterpacks to present their products (rigid PVC, PETG/Barex tamperproof and transparent packaging), such as:
automobile accessories and spare parts,
electrical parts (sockets, switches, etc.),
electronic accessories and spare parts (multimedia and computer components),
audio and video equipment accessories and spare parts,
photography items (cameras, cartridges, accessories),
sport items and accessories,
telephones,
tools,
toys (cars, dolls),
etc…
THIMONNIER manufactures semi-automatic or automatic blisterpack machines.
|
|
|
IWK Verpackungstechnik GmbH offer solutions for unconventional and extraordinary packaging requirements, especially in the field of solida for the pharmaceutical industry. A gap has been closed in IWK´s primary packaging machinery program through the development of a new blister machine generation.
|
|
|
|
