Cutting with scissors is tedious and fatiguing. Eastman rotary shears replace scissors and quickly cut intricate markers, one of a kind patterns, samples, reworks, plastic and rubber sheeting. Offering ultimate maneuverability, Eastman's Rotary Shears are the solution to low quantity cutting jobs common in the industry.
|
|
|
|
|
|
The APS model is the perfect line to have a quick punching and cutting activities for profiles from 30x30 to 160x160x19 mm equipped by:
- A strong main body welded.
- Feeding system equipped by rollers driven by Brushless motor
- Separate Encoder for the feeding lenght management
- N. 2 punching units of 80 Tons, with axes driven.
- N. 1 cutting unit for profiles
- With standard equipment you can fit punches and dies from 5 mm up to 32 mm.
- Feeding units 6 meters
- CNC system for axes X, Y e Z management and punching cutting activities
- Pieces counter
- Set up for a different length, holes numbers and coordinates
- Programs archive
- Display Diagnostic System
- Hydraulic control unit complete with oil.
- CE certificate of conformity
SOFTWARE:
The APS is equipped with the latest generation of software. The program can work with the pieces saved in a data base and also enables designs of several pieces in one, nesting different parts in a sequence optimising the smallest amount of wasted material.
A DXF or DSTV converter is also available as option having the possibility to import and convert these files.
|
|
1. Adopt three-points rollers guide, through the force to the front roller by the papilionaceous spring, the cutting beam keeps in touch tightly with the two back rollers.
2. The special worktable structure designed from limit-element optimization make the curving Sx, which is formed during shearing, to be able to compensate the curving of upper beam under the acting of shearing force, assuring the blade gap to keep same along the full length of worktable, enhancing the shearing precision and quality.
3. GS adopt the compact hydraulic system of B O S C H , advanced compact structure design, the system pressure control adopt electro-Hydraulic proportional valve, the system pressure in a whole working period can be controlled by programming to ensure a stable working performances.
PLEASE WRITE ALL ENQUIRIES ONLY IN ENGLISH!
|
|
1. CE certification
2. All steel welded construction
3. Adopt three-points rolls guide
4. Ball worktable
5. Front sheet support arms
6. High quality shear blades
7. Front finger guard, side guard
8. OMRON photoelectric rear safety guards
PLEASE WRITE ALL ENQUIRIES ONLY IN ENGLISH!
|
|
It’s one of the most advanced miniature mechanical precision shear, and enjoys good reputation both at home and abroad. The low cutting angle and inclined shear direction reduces bowing and twist to a minimum, Blade clearance is easily set by a manually operated quick set device. It’s an ideal true-cut machining equipment of metal sheet and nonferrous metal sheet.
PLEASE WRITE ALL ENQUIRIES ONLY IN ENGLISH!
|
|
|
|
|
|
With its 2 mm capacity and 3100 mm cutting length the RAS SMARTcut combines all characteristics of a premium shear. The sheet support and sorting system leads the blanks to the backstop and sorts cut pieces to the front or the rear. When material thicknesses change, the blade clearance can be adjusted in seconds. The front and side beveled shear tables, the hardened squaring arm and the deep grip hollows simplify material handling for quick results.
The SMARTcut comes with two machine models. The highest comfort level is offered by a best value, fast and dynamic CNC-backstop. Easy to operate and for lower budgets is the manual backstop, which can be positioned from the front. Both backstops offer a travel range of up to 750 mm. A foot lever determines, whether the part chute delivers the cut pieces to the front or the rear. This allows the operator to separate trim cuts or small parts from large parts without additional, later on sorting effort.
The innovative RAS SMARTcut uses the modern swing beam principle instead of the traditional guillotine concept. The upper blade penetrates the material above the lower blade and with a blade angle of as little as 0.9 degrees. This results in clean and twist free cutting of even small strips.
|
|
|
|
|
|
The hydraulic swing beam shears of the RAS POWERcut series are available with capacities of 3190 x 6.3 mm and 4040 x 5 mm. The controller positions the CNC backgauge with an accuracy of +/- 0.1 mm. The CNC can be moved along the front of the machine.
The integrated part sorting system separates good parts from scrap and can sort fin-ished parts using one out of three angles. The Return-to-Sender-function automati-cally feeds a part from the rear back to the operator. This saves the operator most walks around the machine. Small parts can be delivered into a small parts box in front of the machine. Trim cuts fall into a large volume scrap container.
The VARIO shear table with beveled supports and integrated ball casters simplify handling of even large and heavy blanks. Thanks to the big finger pockets, the opera-tor can grasp small strips as little as 50 mm. Moveable table extensions support even large blanks.
75 strokes per minute assure high throughput. The swing beam technology provides very straight and accurate cuts. A blade angle of only 1.4 degrees brings torsion-free cuts already with even small strip widths.
|
|
The C2006 has a motorised rear buffer and a numerical control unit for greater efficiency.
- Cyclical cutting control.
- Illuminated cutting area.
- Upper and lower cutters with 4 blades.
- Optical-electronic safety device.
- 190 mm cutting neck.
- Cut material output ramp.
- Three 1,000 mm support arms
|
|
|
|
|
|
VS SERIES
CNC Variable Rake Shears
The serie provide versatility along with the technology and construction for shearing thin narrow strips or the precision processing of large plates.The upper beam which carries the upper blade is guided by adjustable preloaded and hardened guide ways, a system normally found in much more expensive machines.Both the rake angle and the blade clearance are adjusted hydraulically reducing maintainence and providing overload protection.
The rake angle can be reduced as low as 30 degree reducing distortion in the sheared blank.This can be especially beneficial in the shearing of narrow strips.
The operator simply enters the material thickness, type and back gauge dimension,and the CNC Control automatically calculates the optimum setting of the blade gap and blade clearance.This reduces operator involvment and setup times.
Standard equipments
CE-Norm for EU
DNC Control back gauge-Cybelec DNC 60
Motorized blade gap adjustment by DNC
Variable cutting length by DNC
Rake angle adjustment by DNC
Table with ball transfers
Ball screw Back gauge 1000 mm
1 mt flip-up finger guards
1 Squaring arm L= 1500 mm, with scale & T-Slot
2 Support arms L=1000 mm, with T-Slot
Illumination
Shadow line
Durma has also SB ( Swing beam ), ES ( Hydraulic Guillotine), MS ( Motorised Shear ) in the product ranges.
|
|
Circular Shears
•closed clamping bow
•hydraulic upper blade adjustment
•Ø 500 - 5000 mm x 8 - 20 mm
•PLC-controlled
•automatic charging
|
|
The E-volution in the shearing process is defined by the innovative technology of the new generation of Safan shears: the SAFAN M-Shear and the SAFAN B-Shear. In these shears, the control technology has evolved from hydraulic to electronic. The drive of the cutting beam consists of a servo-electronic motor and a hydraulic pump.
This unique hybrid drive makes the shears more environmentally friendly, low-noise and energy efficient. Their programmable cutting beam starting position, a variety of automatic settings, Touch Screen control and other features give these shears unmatched efficiency.
The fully equipped SAFAN M-Shear is available in working lengths from 2 to 8 metres and capacities from 4 mm to 16 mm sheet thickness. The SAFAN B-Shear is a simpler basic version, produced in one standard model only, that features the same superior technology.
|
|
|
ERMAK CNCHVR angle adjustable hydraulic guillotine shears are strong and easy to use machines which are able to cut any type of sheet with the best quality and speed. Machines could be programmed easily with the use of dialog programs on CYBELEC control units. When the type, thickness and length of the sheet is entered to the controller, machine calculates and adjusts blade gap adjustment, backgauge distance, cutting length and cutting angle automatically. Cutting angle adjustment is done automatically according to sheet thickness, so during cutting thin sheets, the shortest stroke is used.
|
|
Hydraulic Guillotine Shears
For Small- or High-volume Production
HACO has over thirty years of experience in building hydraulic guillotine shears. This expertise guarantees that you get virtually indestructible high-quality machines of great efficiency. We have hydraulic guillotine shears able to handle up to 32 mm thick mild steel sheets. Our machines can cut sheets up to 10 meters long. HACO has the best tool for all your sheet metal cutting jobs.
The program consists out of :
- TS : economic guillotine shears: 06 and 12mm capacity
- HSL : production guillotine shears : 06 up to 16mm capacity
- PS : 'heavy duty' production shears : 06 up to 32 mm capacity
- SST : swing-beam guillotine shears : 04mm
|
|
- Universal stencil owner
- stamping machines from holes to 38 mm
- type- enterprise and adjustable stroke length
- center pressure lubrication
- machines with small maintenance requirement
- five work stations (Compact 40, four work stations)
|
|
|
|
|
|
With its 3 mm capacity and 3100 mm cutting length the RAS PRIMEcut combines all features a critical user expects from modern shearing technology. Innovative swing beam technology offers clean and right-angled cuts. Twist-free cutting of small strips is no longer a problem due to the low rake angle of as little as one degree. Special blades are ideal for mild steel and well as stainless steel applications.
The CNC backgauge positions the part within it's travel range of 750 mm. The parts are in a perfect right angle due to the hardened and self-cleaning squaring arm. Beveled table panels and large grip hollows are ideal for quick and easy material handling. A hold down with plastic coating clamps the material gently during the cut.
The machine is complete with a standard sheet support and material sorting system. The integrated sheet support system guides all materials reliable and straight to the backstop. Using a foot lever, the operator determines, whether the parts will be delivered to the front or the rear. This allows material sorting during the cutting process. The quick blade clearance adjustment sets the machine for perfect and clean cuts on thick or thin materials.
|
|
The demand for a high-performance machine to cut circles for mass production of sheet metal articles, has lead to the development of the Automatic Circular Shear Aryma.
The Automatic Circular Shears Aryma guarantee in their range of capacity a perfect performance and above average efficiency. Aryma Circular Shears are sold in 30 countries all over the world. The machines are manufactured of first-class material only, and it is our general policy to also guarantee an equal workmanship. Our customers are appreciating the Aryma machines for the high cutting quality and the practically service-free operation.
|
|
|
|
|
|
Hydraulic Guillotine Shears
BuCut H
Well engineered BuCut design is examined all problems that occured during cutting process. BuCut hydraulic guillotine shears provide high quality sheet metal cutting process with safety specifications.
The solid design with strengthen welded frame, BuCut is equiped according to customer preference. In this case you can find out friendly, reliability, precision and low maintenance in BuCut hydraulic quillotine shears.
BuTek Machinery has been designing and manufacturing special purposes machine for international companies. This time we reperesent state-of-art machine series BuCut Hydraulic Guillotine Shears with years of experience in sheet metal forming technology
Automatic blade gap adjustment provides cutting in different thickness of sheet metal.
Ergonomic and solid design with strengthen frame, quiet and high performance hydraulic unit, over-load protection and maintenance-free, these provide maximum productivity.
The rolling balls on the work table provides facility in cutting different length of sheet metal.
Hydraulic hold downs start before cutting and after that backguage is moving back side. These protect any deformation in sheet metal.
Advantages of BuCut
Programming BuTech Controller,
Backguage with ball-screw,
The open design of the hand quard provides for cutting small sheet,
Electronic positioning control,
Quiet and powerful hydraulic system
Cutting line illumination,
Light quards,
Support with T-slot and measuring tape,
Hydraulic over-load control,
Emergency stops,
|
|
|
We design and manufacture a full line of shearing equipment, including conventional and CNC-controlled guillotine shears and a CNC production cell with automatic sheet feed.
|
|
The hydraulic shears of the HS series are the ideal machines for those customers who want to have the best possible quality-price ratio in the field of bar shearing.
These simple and sturdy machines can meet all the requirements of the medium/small forging shops.
|
|
CAPACITY RANGE
Shearing capacity : from 6 to 30 mm
Shearing length : from 3100 mm to 8100 mm
MAIN FEATURES
- Heavy-duty "variable rake" design with throat
- Welded all steel frame providing maximum rigidity and cutting accuracy
- Extra-deep (350 mm) side frame throat allowing continuous strip slitting
- Power backgauge on ballscrews
- Swing-up backgauge for shearing longer pieces than backgauge range limit
- Backgauge retract function
- Compact, low-maintenance hydraulic unit
- Hydraulic holddown system
- Hydraulic overload protection
- Centralised manual lubrication system
- Adjustable stroke length to increase number of strokes on shorter cuts
|
|
The horizontal mechanical shears with high cutting speed serie Caddy allow the production of considerable quantities of slugs at low costs, ensuring the dimensional accuracy required by the modern forging technologies - cold, warm, hot and also with closed die.- Horizontal construction:no foundation required.
- Shear rotation for the perpendicular cutting even of material with low tensile strength.
- Simple and quick adjustment of the blade clearance.
- Quick change system for the blades.
- Hydraulic clutch for high performances, long life, absolutely quiet (starting from model Caddy 52F)
- Low maintenance costs
- Fully automated loading, feeding, shearing and unloading cycles.
|
|
|
|
|
|
Mechanical Guillotine Shears
BuCut M
BuCut is designed for high precision cutting operations. In thin sheet, you need high precision cutting without burr. At that point BuCut provides perfect solutions.
BUTEK Company is manufacturer of special purposes machines for Automotive Industries.
BUTEK is experienced of sheet metal forming process and now we represet state-of-the-art machines.BuCut Mechanical Guillotine shears.
The rigid body is manufactured with high strength steel and hardened blades are manufactured with high alloyed steel.
Quiet and maintanence free gearbox is combined with electromagnetic motor brake.
Front support arm with roller bearing and steel ruler with set square are proper for cutting large sheet metal.
Base of BuCut design is including safety, useful and serviceable use with standard and optional devices.
High quality ball screwes and precise guide shafts are used at standard back gauge in all types optional NC programming unit enable counter for cutting quantity and simple use.
There is emergency stop button and position control lamp on the foot pedal console.
|
|
DIRECT-DRIVE GUILLOTINE SHEARS
CAPACITY RANGE
RGS 1560x3.5 mm
RGS 2060x4 mm
RGS 2560x4 mm
RGS 3150x3 mm
MAIN FEATURES
- All steel-plate welded construction
- Noise-free, direct drive system with brake motor
- Rigid cutting beam working inside roller bearings and bronze guides
- Precise blade adjustment from top beam
- Mechanical sheet clamping system
- Simple blade-gap system working on slides
|
|
|
Ermaksan HGD series shears are designed superiorly for sheets 10 - 20mm with high quality material and workmanship and produced to be used several years in heavy duty without any problem. Strong monoblock steel weld construction frame retains its rigidity even working in maximum capacity, thus helps to provide a good quality and clean cut. High quality tough top and bottom blades imported from Germany also helps to have good quality cut and provides an easy cut for the machine as well. Small cutting angle decreases twisting to minimum value in narrow sheet cutting.
|
|
CAPACITY RANGE
Shearing capacity : from 6 to 20 mm
Shearing length : from 1600 mm to 4100 mm
MAIN FEATURES
- Heavy-duty swing beam design with throat
- Welded all steel frame providing maximum rigidity and cutting accuracy
- Rapid blade-gap adjustment mechanism
- Power backgauge on ballscrews
- Swing-up backgauge for shearing longer pieces than backgauge range limit
- Backgauge retract function
- Compact, low-maintenance hydraulic unit
- Hydraulic holddown system
- Hydraulic overload protection
- Adjustable stroke length to increase number of strokes on shorter cuts
|
|
Circular shear flanging machine model 3/1300
With upper blade descent and hydraulic slowdown. Hydraulic part clamping system. Cutting diameter shown on a digital display.
Circular shear flanging machine model 5/1800
With upper blade descent and hydraulic slowdown. Hydraulic part clamping system. Cutting diameter shown on a digital display.
Automatic circular shear model 1800/10
Fully automatic line for cutting disks from square plate, with: upper blade descent and hydraulic slowdown. Hydraulic piece locking system. Automatic plate loading / unloading device. Transfer system for stacking the scraps and disks cut.
|
|
Circular shear flanging machine model M3/1600
Two-headed Circular Shear and Flanging Machine for the cut of disks from a front-squared piece and/or from an octagon piece, and the following beading process (without removing the workpiece from the machine). It is a Machine particularly suitable for the making of circular road signs, garden tables, flat bottoms for the tanks, etc.. The machine consists of: Cutting head model 3/… with two motorized blades and blade descent with hydraulic control; Piece tailstock with hydraulic control; Special beading head equipped with: no. 2 blank holder rolls, no. 1 former roller with radius and shape on request, no. 1 forming roller, no. 1 bead roller, no. 1 roller for the possible beading towards the inner part (in this case the former roller must be according to the drawing)
|
|
|
|
|
|
Ursviken Guillotine Shears
Ursviken's shears are one of the most well known hydraulic shears in the world. They are reliable production machines for plate thicknesses 8 to 25 mm and cutting lengths 3 to 6.5 m and are made for cutting heavy plate with relatively small cutting angles (adjustable between 0.5 to 5 degrees). They are also effective for cutting of thin plate.
Ursviken's shears are equipped as standard with openings in the frame to make it possible to cut plates longer than the nominal length of the machine. The hydraulic system is built up by modern block hydraulics with logic elements to enbale even and shock-free operation. Ursviken's shears are available in 16 models.
Ursviken Guillotine Shear - GSA
- Electro-hydraulic setting of the blade clearance
- Steplessly variable cutting angle
- Automatic limitation of the cutting length
- Reversible, divided shear blades
- Hydraulic synchronization of the cylinders
- Shadow light
Ursviken Guillotine Shear - GSB
Ursviken GSB is a powerful shear made for cutting of high tensile materials up to 2" thick and 25' length.
Ursviken Guillotine Shear - GSB is available in 15 models.
|
|
Series Q11 Shearing Machine
Performance
This machine uses single-side machinical srive of beautiful appearance simple constructon .easily operation ,safe and relialbe , it`s widely used in motor ,electrical ,automobile industries and all shops of other industries where ,sheet metal cuting is required.
|
|
|
|
