Three-phase motor FL-70-10brushless48 Vframeless
Add to favorites
Compare this product
Characteristics
- Type
- three-phase, brushless
- Voltage
- 48 V
- Configuration
- frameless
- Applications
- industrial, for medical equipment, for robotics
- Power
201 W
(0.27 hp)- Intensity
0.42 A, 4.4 A
- Torque
0.55 Nm
(0.405659 ft.lb)- Rotational speed
3,500 rpm
(21,991.1486 rad.min-1)- Diameter
70 mm
(2.76 in)
Description
Brushless frameless motor FL-70-10: power, compactness, and ease of integration for your robotics, medical, or embedded systems projects.
- Nominal torque: 0.55 Nm
- Nominal speed: 3500 rpm
- Voltage: 48 V
Technical Specifications:
- No-load current (A): 0.42
- Efficiency (%): >82%
- Back-EMF constant (V/Krpm): 8.34
- Torque constant (Nm/A): 0.12
- Resistance (ohms@20°C): 0.36
- Inductance (mH): 0.51
- Number of pole pairs: 10
- Three-phase connection: Y
- Encoder: Hall+INC
- Weight (kg): 0.25
- Insulation class: F
Codification:
- RMD: Brand name
- FL: Series name
- 70: Stator diameter
- 10: Rotor height
- 250: Nominal power
