Semi-automatic filling machine

bottlefor jarsfor tubes

Product overview
Compact, high-accuracy benchtop liquid and cream filling machine designed for fast, hygienic and efficient small-batch production. All product-contact parts are manufactured from 316L stainless steel and virgin PTFE; pump cylinders are electropolished for improved hygiene and cleanability.

Key features

• Fast, Precise & Versatile — Consistent, repeatable fills with high accuracy, reducing product waste and improving process efficiency for small-batch and laboratory production.
• Wide Filling Range — Supplied with interchangeable pump sets covering a broad volume range to match various container sizes; electropolished pump cylinders for hygiene.
• Flexible Product Feed Options — Liquids drawn from bulk containers via suction hose and non-return valve; thicker products fed from hopper systems with multiple hopper sizes.
• Interchangeable Nozzle Solutions — Range of nozzles for different viscosities and container dimensions including swage tip, cut-off with tip sealing, and full-bore cut-off nozzles for drip-free filling.
• Compact & Convenient Design — Small benchtop footprint suitable for laboratories, pilot plants, batch production runs, start-ups and growing manufacturers.
• Quick-Strip for Rapid Cleaning — Machine fully strips down in as little as three minutes to minimise downtime and support high hygiene standards.
• Product & Container Flexibility — Handles liquids, oils, gels, creams, pastes and products with particulates; suitable for bottles, jars, tubes, vials, pots and similar containers.
• Safe, Reliable & Scalable — Available with one or two filling heads and interchangeable nozzles; upgradeable for automation and integration with multiple benchtop fillers or monobloc filler/capper systems.
• ATEX Configuration Available — ATEX-compliant version available for products that may generate explosive mists or vapours.

Service & Maintenance
All product-contact parts are 316L pharmaceutical-grade stainless steel and virgin PTFE. Standard seal materials include FKM (Viton) with alternatives EPDM, silicone and FFKM available. Food-grade PVC suction hoses are used where applicable. The quick-strip design enables fast, thorough cleaning to meet strict hygiene protocols and minimise production downtime.

What the machine can fill

• Liquids, oils and serums
• Creams, gels and lotions
• Pastes and viscous products
• Products with particulates (e.g. food sauces, cosmetic scrubs)

Technical specifications
Specification | Single Head | Double Head
Typical Product Output | Up to 40 per min | Up to 60 per min
Fill Volume Range | 4 ml – 1000 ml | 4 ml – 100 ml
Machine Height without hopper | 340 mm | 340 mm
Machine Width | 343 mm | 343 mm
Machine Weight | 41 kg | 44 kg
Compressed Air Consumption | 5 L at 6 bar per cycle | 5 L at 6 bar per cycle

Additional technical details

• Filling accuracy: ±0.25% (typical)
• Configurations: single or double head, interchangeable pumps and nozzles
• Materials: 316L stainless steel product-contact parts; PTFE components; FDA/GMP-compliant materials
• Seals: standard FKM (Viton); optional EPDM, silicone, FFKM
• Cleaning: quick-strip design — full disassembly in ≈3 minutes
• Feed: suction from bulk containers or hopper feeding for viscous products
• Options: multiple pump sets and nozzle types, hopper sizes, ATEX version, automation upgrade paths
