Wall-mounted pressure sensor FD 8612 series
relativeabsolutedifferential

wall-mounted pressure sensor
wall-mounted pressure sensor
Add to favorites
Compare this product


Characteristics

Pressure type
relative, absolute, differential
Output
4-20 mA, 0-10 V, voltage output
Supply voltage
230VAC
Mounting
wall-mounted
Material
plastic
Protection level
rugged, rugged, IP54
Applications
for clean rooms
Pressure range

Max.: 500 mbar
(7.25 psi)

Min.: 2.5 mbar
(0.04 psi)

Precision

0.2 %, 0.5 %, 1 %

Process temperature

Max.: 50 °C
(122 °F)

23 °C
(73 °F)

Min.: 10 °C
(50 °F)

Description

Pressure Sensors for Wall Mounting • The robust mechanics guarantees long term stability, linearity and good reproducibility • Designs and specifications see data sheet Technical data and functions • Suitable for use in the laboratory, as well as for use in harsh industrial environments, e.g. HEVAC applications, clean room technology, medical technology, filter technology and finishing pass technology. • The robust mechanics guarantees long term stability, linearity and good reproducibility. • Temperature drift reduced to a minimum by specific compensation of the sensors. • Operation is almost maintenance-free, as a result of the free-from-wear inductive measuring system. • As standard, the integrated electronics provide a pressure proportional voltage signal from 0 to 2V as output.
