Articulated robot NJ-165-3.4 SH

6-axishandlingfor assembly

When Performance Matters We deliver the power to drive your automation while ensuring energy savings, costs reduction and higher productivity. Not bad. Technical specifications Number of axes 6 Additional load on forearm (Kg) 25 Torque on axis 4 (Nm) 1089 Torque on axis 5 (Nm) 804 Torque on axis 6 (Nm) 411 Stroke (Speed) on Axis 1 +/- 180° (85°/s) Stroke (Speed) on Axis 2 -50° / +170° (90°/s) Stroke (Speed) on Axis 3 -18,8° / -288° (110°/s) Stroke (Speed) on Axis 4 +/- 2700° (130°/s) Stroke (Speed) on Axis 5 +/- 125° (130°/s) Stroke (Speed) on Axis 6 +/- 2700° (195°/s) Tool coupling flange ISO 9409 - 1 - A 160 / 200 Protection class IP65 Mounting position Shelf Operating Areas A (mm) 3100 Operating Areas B (mm) 3450 Operating Areas C (mm) 449 Operating Areas D (mm) 397 Operating Areas E (mm) 2100 Operating Areas F (mm) 850
