Chemical pump CR seriesfor food productselectricself-priming
Add to favorites
Compare this product
Characteristics
- Fluid
- for chemicals, for food products
- Operation
- electric
- Priming
- self-priming
- Technology
- spiral
- Mobility
- stationary
- Domain
- industrial, for the chemical industry, for the pharmaceutical industry, for the cosmetics industry
- Other characteristics
- large
- Flow
Min.: 0 m³/h
(0 ft³/h)Max.: 150 m³/h
(5,297.20001 ft³/h)- Pressure
10 bar
(145.038 psi)- Head
Min.: 0 m
(0'00" )Max.: 20 m
(65'07" )- Power
Min.: 0.55 kW
(0.75 hp)Max.: 15 kW
(20.39 hp)- Fluid temperature
Min.: -10 °C
(14 °F)Max.: 100 °C
(212 °F)- Length
Min.: 657 mm
(26 in)Max.: 1,035 mm
(41 in)- Width
Min.: 302 mm
(11.89 in)Max.: 506 mm
(19.92 in)- Height
Min.: 398 mm
(15.67 in)Max.: 593 mm
(23.35 in)
Description
The special spiral impeller, together with the body shape, large volute and reduced operating speed (max. 1750 rpm) make this pump suitable for handling delicate liquids with suspended particles, combining the properties of a centrifugal pump with the delicate handling of a progressive cavity pump. In fact, the "CR" is widely used to handle high consistency products containing solids. For example in the production of wine, beer, transfer of cereals, chopped fruit, vegetables, meat and poultry.
