Bag dust collector DEDUST 10 PRO

for the food industryfor the pharmaceutical industrycompact

Overview
The DEDUST 10 PRO is an industrial dust collector designed to capture suspended fine dust, fumes and small chips in production environments. Compact and mobile, it pairs an overhead electric fan with a polyester pocket filter to provide efficient local extraction while keeping electrical consumption low.

Applications

• Mechanical and metalworking workshops
• Glass processing
• Woodworking and plastics fabrication
• Food, chemical and pharmaceutical production (as applicable)

Vacuum unit
An electric centrifugal fan delivers a maximum air flow of approx. 1,000 m³/h with a maximum depression up to 180 mmH2O, driven by a 0.75 kW motor.

Filtration unit
The primary filtration is performed by polyester pocket filters mounted inside the filter chamber, providing a large filtration area (20,000 cm²) and resistance to clogging for dusty applications.

Collection unit
Collected dust and chips are deposited in a quick-release container with a capacity ranging from 40 to 100 liters depending on the model. The unit is mounted on a wheeled frame for easy repositioning.

Data sheet
Model: DEDUST 10 PRO
Power supply: 400 V, 50 Hz, 3~
Motor power: 0.75 kW
Maximum depression: 180 mmH2O
Maximum air flow: 1,000 m³/h
Nozzle diameter: 100 mm
Primary filter: Polyester pocket filters (20,000 cm² / Ø420 mm)
Dimensions (LxWxH): 71 x 57 x 153 cm
Weight: 60 kg
Dust container: 40–100 L (model dependent)

Technical specifications

• Model: DEDUST 10 PRO
• Power supply: 400 V - 50 Hz - 3~
• Motor power: 0.75 kW
• Maximum depression: 180 mmH2O
• Maximum air flow rate: 1,000 m³/h
• Nozzle diameter: 100 mm
• Primary filter type: Polyester pocket filters
• Filter surface area / diameter: 20,000 cm² / 420 mm
• Dust container capacity: 40–100 L (depending on model)
• Dimensions (LxWxH): 71 x 57 x 153 cm
• Weight: 60 kg
• Mobility: wheeled structure
• Controls: on/off disconnect switch
• Optional: self-supporting arm Ø100 mm, length 3 m
• Optional: ATEX-certified version available
