Water rotary union BR seriesfor oilfor airhydraulic
Add to favorites
Compare this product
Characteristics
- Medium
- for water, for oil, for air
- Applications
- hydraulic, pneumatic, low-pressure
- Material
- stainless steel, carbon steel
- Other characteristics
- with seal, flange, low-speed, large
- Rotational speed
Min.: 0 rpm
(0 rad.min-1)Max.: 20 rpm
(125.66 rad.min-1)- Pressure
Min.: 0 bar
(0 psi)Max.: 100 bar
(1,450 psi)- Nominal size
Min.: 2 in
Max.: 12 in
Description
Rotating flanges allow the transfer of fluids for your installations requiring a large flow (up to 12 inches).
Activities:
– Energy, Environment
– Trading
Surface treatment: Chemical Nickel
Implantation: Straight
Temperature working: -20°C à 200°C
Connection: Flange
PN10, PN16
*for any other type of connection, please contact us.
