Analog I/O module PFAPM0C-QA4G PICO PRO SIO

digitalModbus RTURS-485

Overview
Code: PFAPM0C-QA4G
The PICO PRO SIO is an intelligent input/output and sensor interface module offering 2 digital inputs, 2 digital outputs and 2 analog outputs with SIO Bus expansion and Modbus RTU communication.

Digital Inputs

• Two opto-isolated digital inputs with debounce filtering for reliable pulse counting and remote status monitoring.
• Suitable for counter applications, flow or event detection.

Digital Outputs
Two opto-isolated transistor outputs rated 27 Vdc, 27 mA (DIN 43864). Outputs can be assigned as internal alarm outputs or used as remote-controlled channels via Modbus.

Analog Outputs
Two galvanically isolated analog outputs configurable for 4–20 mA or 0–20 mA signals, providing accurate and stable current outputs for control or monitoring loops.

SIO Bus & Integration
The SIO Bus supports connection of additional I/O modules and environmental sensors through Milli Pro devices, enabling scalable system expansion.

Alarms and Registers
Includes 8 configurable alarms that can drive digital outputs and populate Modbus registers for remote supervision and logging.

Additional features

• Modbus RTU communication over RS485 for integration into SCADA and PLC networks.
• Remote firmware upgrade capability to simplify maintenance and updates.

Power & Mechanical
Power supply: 12 Vdc.
Enclosure: grey. Dimensions: 125 × 40 × 85 mm.

Technical specifications

• Code: PFAPM0C-QA4G
• Designation: PICO PRO SIO
• Power supply: 12 Vdc
• Digital inputs: 2 opto-isolated with debounce filtering (pulse counting / status monitoring)
• Digital outputs: 2 opto-isolated transistor outputs, 27 Vdc, 27 mA (DIN 43864)
• Analog outputs: 2 galvanically isolated channels, configurable 4–20 mA or 0–20 mA
• SIO Bus: supports expansion with Milli Pro devices
• Communication: Modbus RTU over RS485
• Alarms: 8 configurable alarms
• Firmware: remote firmware upgrade capability
• Enclosure: grey
• Dimensions: 125 × 40 × 85 mm
