- FLAPCON VALVES AND AUTOMATION SYSTEMS CO LTD
Plug valve AS seriespneumatically-operatedfor waterfor chemicals
Add to favorites
Compare this product
Characteristics
- Type
- plug
- Operation
- pneumatically-operated
- Media
- for water, for chemicals, for steam
- Body
- threaded, angle seat
- Other characteristics
- normally closed, normally open
- DN
Max.: 100 mm
(3.937 in)Min.: 10 mm
(0.394 in)- Pressure
Max.: 160 bar
(2,320.6 psi)Min.: 0 bar
(0 psi)- Temperature
Max.: 220 °C
(428 °F)Min.: -20 °C
(-4 °F)
Description
Large Flux, low resistance, no water hammer.
Y type shape enlarged the flowing section, which could raise the flux by %30 and make flow more smooth.
Super long working life, which help the stem adjust and lubricate itself automatically. On-Off actions by normally closed or normally open with spring. Double acting type are on request. Positioner addaptable bracket is on request. Plug design can be design according to your flow Cv/Kvs with sensetive accuracy by parabloic design.
AS10 Serie offers plastic headed actuator. AS11 serie offers st. steel headed actuator.
AS11-M is operated with manual wheel for for precise flow adjustment.
