Wooden workbench Nova Max ESD

assemblyfor workshopsindustrial

Overview
ESD workbench Nova Max is an industrial workstation designed for environments that require electrostatic discharge (ESD) protection. It is configured for electronic assembly, laboratories and test benches with manual height adjustment, integrated LED lighting, an adjustable shelf and an integrated power strip.

Construction and ESD compliance

• Steel frame with 40 × 40 mm profiles designed for industrial use and a supported worktop for heavy-duty tasks.
• Antistatic powder coating and conductive frame compliant with IEC 61340-5-1 for ESD environments.
• Rear panel providing cable routing and additional structural rigidity.
• Manual height adjustment range 680–1130 mm to enable seated or standing work.
• Adjustable feet for floor levelling (up to 30 mm correction).

Materials and finish

• Worktop: FSC-certified laminated particleboard with dissipative melamine surface, 25 mm thickness, easy to clean.
• Frame: antistatic powder-coated steel available in RAL 7035 (Light Grey), RAL 7016 (Anthracite) or a combination.

Features

• Adjustable full-width shelf: standard depth 300 mm (optional 400 mm), tilt 0°/10°/15°, shelf load capacity 15 kg.
• Integrated power strip: 7 Type‑E sockets with main switch and surge protection.
• LED lighting: microprismatic, 5000 K, Ra > 80, adjustable ±60°, life 50,000 h.

  • Luminous flux: 3822 lm (≈1226 lux) for widths up to 1600 mm.
  • Luminous flux: 4778 lm (≈1533 lux) for widths from 1800 mm.

Applications

• Electronic manufacturing and PCBA assembly.
• Inspection, test benches and measurement laboratories.
• R&D workshops, repair and calibration areas.

Available sizes and options

• Worktop sizes available: 1200×700; 1500×700; 1600×700; 1800×700; 2000×700; 1200×800; 1500×800; 1600×800; 1800×800; 2000×800; 1200×900; 1500×900; 1600×900; 1800×900; 2000×900; 1200×1000; 1500×1000; 1600×1000; 1800×1000; 2000×1000.
• Options: additional shelves, perforated rear panels, drawer modules, extra power strips and IT accessories (monitor arms, keyboard trays).

Sustainability and warranty

• Delivered in eco‑friendly, plastic‑free packaging.
• 5‑year warranty on metal parts.

Technical specifications

• Height adjustment range: 680–1130 mm (manual).
• Load capacity: 300 kg (evenly distributed).
• Worktop thickness/material: 25 mm laminated particleboard, dissipative melamine surface (FSC).
• Frame profile: 40 × 40 mm steel.
• Shelf depth: 300 mm standard (optional 400 mm); tilt 0°/10°/15°; shelf load 15 kg.
• Power strip: 7 Type‑E sockets, main switch, surge protection.
• LED: 5000 K, Ra > 80, adjustable ±60°, life 50,000 h; luminous flux 3822 lm / 4778 lm depending on width.
• Frame finish: antistatic powder coating (ESD properties).
• Adjustable feet: height correction up to 30 mm.
• Lead time (indicative): 2–3 weeks.
