Assembly workstation Summit Edge ESD

for laboratoryweighingcounting

The Summit Edge ESD is a manually height-adjustable workbench built on a C-leg frame. The open C-leg design provides more legroom and a cleaner visual profile than an H-frame, making it well suited for assembly lines, technical workstations, electronics production, and laboratory environments.

The Edge configuration Fully equipped workstation with integrated lighting, power, and drawer storage.

Included: Extension frame + LED light + light holder + shelf + power strip (7 sockets) + lockable drawer unit (2 drawers, 40 kg total).

Technical specifications:

• Height adjustment: Manual, 705–1120 mm
• Load capacity: 300 kg
• Frame: C-leg frame
• Worktop widths: 1190 / 1490 / 1590 / 1790 / 1990 mm
• Worktop depths: 690 / 790 / 890 mm
• Worktop thickness: 25 mm, melamine-coated particleboard
• Frame colours: RAL 7035 (light grey) / RAL 7016 (anthracite) / MIX

ESD-compliant. ESD-certified according to PN-EN IEC 61340-5-1:2025-02 (IEC 61340-5-1:2024).

All configurations can be further customised — dimensions, colour, accessories — on request.
5-year warranty on all metal components.
