Methane analyzer GA220

carbon dioxidemonitoringprocess

Overview The Gas Analyzer 220 - Biomethan is a stationary online gas analyzer optimized for precise, long-term stable measurement of high methane concentrations (biomethane). Designed for demanding process environments, it provides drift-free results, fast response and straightforward integration into industrial control systems.

Application The Gas Analyzer 220 - Biomethan is developed for continuous online monitoring of methane in biomethane production and upgrading. Measurement range: 0.1–100 Vol.-% CH₄. Robust measurement control and automated zero-point correction ensure reliable data under variable process conditions.

Features

• High long-term stability: patented automatic zero-point correction minimizes drift.
• Built-in sampling: integrated membrane pump for autonomous sample supply at ~4 l/min.
• Extensive interfaces: RS232 (standard); optional Profibus DP, Ethernet Modbus TCP, Profinet; up to 8 analogue outputs (4–20 mA).
• User interface: 128 × 64 pixel monochrome touch display for intuitive operation and quick parameter changes.
• Compact industrial housing: 19" rack-mount (400 mm depth), protection class IP20.

Use cases

• Biomethane plants: continuous CH₄ monitoring for process control and product quality assurance.
• Power-to-Gas plants: methane monitoring in methanation to verify gas quality.
• Combined heat and power (CHP) units: CH₄ measurement for optimal energy conversion and safety.

Measurable substances

• CH₄ — Methane
• CO₂ — Carbon dioxide (optional)

Key data / Facts

• Measurement range: 0.1–100 Vol.-% CH₄
• Measurement interval: 20 seconds
• Measurement accuracy: < 1% of reading
• Detection limit: 0.1 Vol.-%
• Warm-up / readiness: measurement ready in 5 minutes; full specification after 30 minutes
• Supply voltage: 230 V AC / 50 Hz (0.9 A / 207 VA); other options available
• Housing: 19" rack, 400 mm depth, IP20

Technical data (excerpt)
Measurement method: IR — NDIR single‑beam, heated measurement cell (60°C)
Measuring component: 1 × NDIR (CH₄ or CO₂)
Measuring range: 0.1–100 Vol.-% CH₄
Measurement accuracy: < 1% of reading
Detection limit: 0.1 Vol.-%
Measurement interval: 20 seconds
Electrical interfaces: RS232 (standard); optional Profibus DP, Ethernet Modbus TCP, Profinet; up to 8 analogue outputs (4–20 mA)
Supply voltage: 230 V AC / 50 Hz (0.9 A / 207 VA); other supply options available
Housing: 19" rack, 400 mm depth, protection class IP20
Operational readiness: measurement ready in 5 minutes; full specification after 30 minutes

Specifications / Technical specifications

• Measurement principle: NDIR single‑beam, heated cell at 60 °C
• Measured gases: CH₄ (standard), CO₂ (optional)
• Measuring range CH₄: 0.1–100 Vol.-%
• Accuracy: < 1% of reading
• Detection limit: 0.1 Vol.-%
• Measurement cycle: 20 s
• Sample flow: integrated membrane pump, approx. 4 l/min
• Interfaces: RS232 (std); optional Profibus DP, Modbus TCP, Profinet; up to 8 × 4–20 mA
• Power supply: 230 V AC / 50 Hz (0.9 A / 207 VA) — further options available
• Form factor: 19" rack-mount, 400 mm depth, IP20
• Warm-up / readiness: ready in 5 min, full specification after 30 min
