Removable immersion heater

flattank bottomstainless steel

Overview
Galvatherm® foot-mounted flat-plate immersion heaters provide an industrial heating solution combining efficiency and installation flexibility. Designed for bottom-of-tank installation, they deliver a large heat exchange surface while minimizing tank space usage.

Technical Specifications

• Power: Available from 0.5 kW to 15 kW (particularly suitable up to 6 kW).
• Materials: Metal frame with coating options PP, PVDF, PFA or uncoated stainless steel.
• Mounting: Designed for bottom-mounted installation with stable feet (standard foot height 50 mm).
• Heating cable: Insulated with PFA fluoropolymer.

Key Benefits

• Enhanced stability: PP or PVDF feet ensure reliable positioning at the tank bottom.
• Increased protection: Optional removable perforated protector prevents direct contact and protects the heater from mechanical shock.
• Space optimization: Low-profile mounting with standard 50 mm foot height, suitable for most industrial tanks.

Main Applications

• Tank bottom installation: Optimized for heating liquids directly at the bottom of industrial tanks.
• Frost protection: Suitable for maintaining fluid temperature in freezing conditions.

Safety and Compliance

• Meets the requirements of EN 60519-1/2.

Options and Accessories

• Ø75 mm cable gland (PP ref: PEPP, PVDF ref: PEPF) — allow 300 mm clearance on length H (mounting height on N).
• Cable extension — power cable C of type HO5 VV-F or HO7 RN-F; separate non-heating cable N for tank outlet.
• Removable perforated protector for A (PP ref: PRPPP, PVDF ref: PRPPF) — protects the heater from mechanical shock and prevents direct contact.
• PP or PVDF feet for tank bottom installation (standard height 50 mm) — PP ref.: PIPP, PVDF ref.: PIPF.

Documentation
Data sheet available for the Flat Immersion Heater (A-mount + feet). Installation manual for Galvatherm® available.

Technical characteristics / Specifications

• Power range: 0.5 kW – 15 kW (recommended up to 6 kW for typical applications).
• Frame materials/coatings: PP, PVDF, PFA or stainless steel (uncoated).
• Mounting type: Bottom-mounted (A-mount) with stable feet; standard foot height 50 mm.
• Heating cable insulation: PFA fluoropolymer.
• Optional protection: Removable perforated protector in PP or PVDF.
• Power cable options: HO5 VV-F or HO7 RN-F (power cable); separate non-heating cable for tank outlet.
• Standards: Compliant with EN 60519-1/2.
