Desktop keyboard K-TEK-V318TP-FN-BL-FC-SC-ML-FDT-DWP

scissor switch88-keywith 2 mouse keys

Overview
Fully sealed 88-key industrial keyboard with 2 integrated mouse buttons and a reinforced, wide-temperature, fully sealed touchpad (400 DPI). Equipped with rugged scissor-switch keys (1.20 mm ±0.10 mm travel) and a flip-up hinge for secure tablet attachment. Front panel protection IP68. Designed to operate across extreme environmental conditions and to meet MIL-STD-810H test items.

Dimensions
318.0 mm x 235.0 mm x 31.0 mm (L x W x H).

Mechanical data

• Keys: 88 (including 2 mouse buttons)
• Key switch: Rugged scissor switch technology
• Key travel: 1.20 mm ±0.10 mm
• Key life span: > 5 million operations
• Actuation force: 0.8 N ± 0.2 N

Electrical data

• Supply voltage: DC +5V ±5%
• Current rating: ≤ 30 mA (backlight off); ≤ 300 mA (backlight on)
• Interface: Dot-matrix, USB, PS/2 available
• Backlight: Adjustable white
• OS compatibility: Windows, Linux, Unix, Mac OS X, VxWorks, Android

Environmental adaptability
Operating temperature: -40°C to +60°C. Storage temperature: -50°C to +70°C. Tested for humidity cycles (95% RH), atmospheric pressures 57–106 kPa, vibration, shock (peak 40 g, 11 ms), temperature shock cycles, fungus, salt spray, rain and dust according to specified procedures. Transport package drop test: up to 122 cm on each face, edge and corner.

Reliability & certifications
RoHS compliant, CE and FCC certified. Meets MIL-STD-810H environmental test items. Product lifespan > 5 years. MTBF > 20,000 h; MTTR < 30 min. Patent: 202422198937.6.

Applications

• Vehicle systems
• Aerospace
• Naval and maritime systems
• Defense and radar consoles
• Portable rugged laptops and UAV ground stations

Technical specifications

• Model family: K-TEK V318TP
• Category: DWP Scissor Switch Keyboard
• Protection level: IP68 (front panel)
• Touchpad: Fully sealed, reinforced, wide-temperature, 400 DPI
• Interfaces: Matrix/USB/PS/2
• Dimensions (L x W x H): 318.0 mm x 235.0 mm x 31.0 mm
• Supply voltage: DC +5V ±5%
• Current rating: ≤30 mA (backlight off); ≤300 mA (backlight on)
• Key life: >5 million operations
• Certifications/standards: RoHS, CE, FCC, MIL-STD-810H
• Patent: 202422198937.6
