Single-phase electric energy meter MCM1M-163W

DIN rail60 Hzwith built-in communication

The MCM1M-163W single-phase meter allows monitoring of electrical consumption via a smartphone application, and its integrated relay enables it to meet a wide range of applications: - Electrical: Multifunction energy meter for single-phase 230V 50/60Hz network. Direct connection up to 63A. - Measured Data: The sub-meter measures a multitude of electrical quantities: Active energy (kWh): imported, exported, total, imported-exported. Reactive energy (kVArh): total. Instantaneous values: Voltage (V), current (U), active power (kW), reactive power (kVAr), power factor (cos Phi), frequency (Hz). - Measurement Accuracy: Class 1 for energies and class 0.5 for instantaneous values. - WiFi Communication: The sub-meter can connect to the local WiFi network to be fully controlled via a free home automation smartphone application. - Contactor Function: The internal relay allows cutting the measured phase. It can be switched manually or programmed to operate on threshold attainment, according to a time slot, or based on electrical consumption, etc. - Physical: DIN rail mountable meter, 1 module wide housing. - Electricity Consumption Monitoring: Consumption histories are recorded and viewable on the smartphone app. Hourly, daily, and monthly indexes are displayed on a simple and intuitive interface. - Alarm and Circuit Protection: Circuit interruption can be programmed on reaching minimum or maximum thresholds, for load shedding, alarm, or protection functions. The smartphone app allows sending notifications, SMS, or calls in case of alarm triggering. - Remote Circuit Control: The WiFi-controllable contactor function allows activating or deactivating a device or electrical circuit remotely. Very useful, for example, to activate heating remotely. - Time Programming: The smartphone app allows programming the internal relay according to a schedule, to activate electrical devices during a defined time slot (timer function). - Data Export: The history of data measured by this single-phase meter can be exported by email in CSV format. - Prepayment: The application allows allocating a certain number of kWh. Once exhausted, the internal relay cuts the circuit. - Integration Simplicity: Meter housing only 1 module wide (18 mm). - Circuit Control: The integrated cut-off relay allows controlling electrical devices remotely or according to a multitude of conditions. - Extended Features: Prepayment, time programming, consumption monitoring, data export, alarm, etc. The MCM1M-163W single-phase meter meets a wide range of applications. - Compliance: CE, RoHS. - Applicable Standards: IEC62053-21, IEC62052-11. - Technical Resources: Product datasheet, installation and user manual, general catalog available for download. - Technical Specifications: - Type: Single-phase connected energy meter with contactor function - Maximum current: 63A - Direct connection - WiFi communication - DIN rail mounting, 1 module width - Measurement accuracy: Class 1 (energy), Class 0.5 (instantaneous values) - Measured values: Active and reactive energy, voltage, current, active and reactive power, power factor, frequency - Integrated relay for circuit control - Programmable alarms and schedules - Data export in CSV format - Prepayment function - Compliance: CE, RoHS - Standards: IEC62053-21, IEC62052-11
