Four shaft shredder F series

for medical wasteindustrial wastefor cardboard

Product overview
The F series four-shaft shredder is a modular, industrial shredding unit designed for reliable size reduction of diverse waste and scrap streams. It features repairable special-alloy cutting blades, dual-motor drive with heavy-duty planetary gearboxes and PLC-based electrical control with touch-screen interface and video monitoring.

Cutting principle
Material is shredded between four counter-rotating shafts and discharged through a screen mesh that controls the particle size. Material smaller than the screen openings exits; oversize pieces are guided back by the main and auxiliary knives for repeated cutting until they pass through the sieve.

Key features

• Screen-controlled discharge ensures consistent particle size and uniform output.
• Four cutting shafts enable high throughput and single-pass reduction for many materials.
• Dual-motor drive with heavy planetary gearboxes provides differential shaft speeds for efficient shearing.
• Special-alloy main blades are repairable (cladding/welding) to extend service life and reduce blade cost.
• Enclosed bearing housings with waterproof and dustproof seals to prolong bearing life.
• Integral-machined rotor (no weld seams) and shear-type moving knives reduce wear and maintenance time.
• Auxiliary cutting blade groups assist in gripping and breaking large items.
• PLC control with touch screen supports start/stop/reverse and automatic overload detection/protection to safeguard components.
• Low rotational speed combined with high torque reduces noise and improves safety for industrial recycling environments.

Applications

• Containers: plastic buckets, metal drums, paint cans, IBCs, waste bins.
• Municipal and industrial wastes: household waste, medical waste, kitchen and park waste.
• Plastics: bottles, frames, blocks, plastic cans.
• Metals: aluminum profiles, oil filters, vehicle body parts, metal cans.
• Paper: newspapers, cardboard, corrugated paper, copy paper.
• Electronics: refrigerators, PCBs, laptop shells, TV housings, CDs.
• Glass: glass wool, shards, bottles.
• Textiles and leather: fabrics, fibers, clothing.

Notes

• Supply voltage and electrical configuration can be adapted to customer requirements.
• Throughput depends on material properties and target output size defined by the screen.
• Specifications are indicative and subject to change; confirm details when ordering.

Technical specifications

• Series: F series (four-shaft configuration)
• Blade material: special alloy steel, repairable by welding/coating
• Drive: two motors with heavy planetary gearboxes; differential shaft speeds
• Control: PLC with touch-screen HMI and optional video monitor; automatic overload detection/protection
• Operation: low rotation speed, high torque, reduced noise
• Transmission: motor + reducer + coupling; gear linkage between driving and driven shafts
• Bearing protection: fully enclosed, waterproof and dustproof sealing
• Discharge control: screen mesh to regulate output particle size
